Communication Settings — This panel contains the current TCP/IP and RS-232
3
connection settings.
To edit the TCP/IP settings:
1. Click the button. The following dialog box opens:
Edit
Figure 96. Communication Settings Dialog Box
2.
Enter the desired settings in the
Default Gateway
fields).
Alternatively, select the
from a DHCP server.
To reset all addresses to their factory defaults, click
Reset on the confirmation prompt that opens.
3. Click to confirm the settings and close the dialog box.
Apply
Device Info — Contains the name, part number, model name and description, firmware
4
version and build numbers, and the current internal temperature of the MediaPort
device. In this panel the device name and USB name recognized by Windows can be
viewed and edited. Firmware can also be updated from this panel.
NOTE: Firmware can only be updated via TCP/IP connection.
Figure 97. Device Info Panel
,
IP Address Subnet Mask
fields (the Use DHCP checkbox must be cleared to edit these
checkbox to have the unit obtain its IP address
Use DHCP
MediaPort 200 • Remote Configuration and Control
, and
, then click
Reset to Default
