Extron electronics IN1606 series User Manual

Scaling presentation switchers
Hide thumbs Also See for IN1606 series:
Table of Contents

Advertisement

Quick Links

See also: Setup Manual
User Guide
Scalers
IN1606
IN1608 Series
Scaling Presentation Switchers
68-2290-01 Rev. F
07 15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN1606 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extron electronics IN1606 series

Summary of Contents for Extron electronics IN1606 series

  • Page 1 User Guide Scalers IN1606 IN1608 Series Scaling Presentation Switchers 68-2290-01 Rev. F 07 15...

  • Page 2: Safety Instructions

    Safety Instructions Safety Instructions • English Инструкция по технике безопасности • Русский WARNING: This symbol, , when used on the product, is intended to ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан alert the user of the presence of uninsulated dangerous voltage within the на...
  • Page 3 ATTENTION : Risque d’explosion. Ne pas remplacer la pile par le mauvais type de pile. Débarrassez-vous des piles usagées selon le mode d’emploi. Copyright © 2015 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners.
  • Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: ATTENTION: • Risk of property damage. • Risque de dommages matériels. NOTE: A note draws attention to important information. TIP: A tip provides a suggestion to make working with the application easier. Software Commands Commands are written in the fonts shown here: ^AR Merge Scene,,Op1 scene 1,1 ^B 51 ^W^C...

  • Page 5: Table Of Contents

    Contents Quick Setup Submenu........27 Introduction ........... 1 User Presets Submenu ......... 28 About this Guide ..........1 Picture Controls Submenu ......29 IN1606 and IN1608 Series Description ....2 Input Submenu ..........30 Licensed Third-Party Software Used in the Output Submenu ..........
  • Page 6 Configuration Software Reference Information ........65 ......123 Software Installation.......... 65 Mounting ............123 Software Download Center Page ....65 Tabletop Mounting ........123 PCS Product Page ........66 Rack Mounting ........... 123 Software Connection ........67 Furniture Mounting........124 Device Discovery Panel .........

  • Page 7: Introduction

    Introduction This section provides general information about this guide and the Extron IN1606 and IN1608 Series. Topics in this section include: • About this Guide • IN1606 and IN1608 Series Description Licensed Third-Party Software Used in the Scalers • • Key Features Control Methods •...

  • Page 8: In1606 And In1608 Series Description

    The following terms refer to groups of IN1608 models: • The term “IN1608 Series” refers to all IN1608 models. • The term “-0x models” refers to IN1608, IN1608 SA, and IN1608 MA models with DTP 230 extension. • The term “-5x models” refers to IN1608, IN1608 SA, and IN1608 MA 70 models with DTP 330 extension.
  • Page 9 To enhance and simplify integration of HDMI sources and displays, the scalers feature two exclusive Extron technologies: EDID Minder and Key Minder. EDID Minder manages Extended Display Identification Data (EDID) communication between the display devices and input sources. For HDMI signals with protected content, Key Minder authenticates and maintains continuous HDCP-encryption between input and output devices.
  • Page 10 The following diagram shows an example of a typical application for the IN1606. Extron XPA 1002 Extron Power SI 28 Ampli e TouchLink Surface- Control mount System Speakers Audio TCP/IP Extron M OT W IR Network IN1606 Flat Panel X PA ∞...
  • Page 11 The following diagram demonstrates an example of a typical application for the IN1608 SA. Extron Extron SI 28 DTP HDMI 230 Rx RS-232 Surface- Receiver TouchLink mount Speakers Control System TCP/IP Network Extron IN1608 SA RS-232 A MA D TP Scaling Presentation ®...

  • Page 12: Licensed Third-Party Software Used In The Scalers

    Licensed Third-Party Software Used in the Scalers The scalers use various licensed third-party software packages during operation. To view details about third-party packages and associated licensing, click the License button on the page of the internal Web pages (see Unit Information Unit Information Information Page...

  • Page 13: Key Features

    Key Features Video Features Multiple input types — Allow for switching between HDMI and analog video sources. • Two configurable analog inputs accept most standard analog video formats, including RGB, HD component video, S-video, and composite video signals. HDMI, HDTV, RGB, and video source integration into presentation systems with •...

  • Page 14: General Features

    General Features Interface format correction — Enables or disables embedded audio and InfoFrames, • and sets the correct color space for proper connection to HDMI and DVI displays. • Supported HDMI specification features — Includes data rates up to 6.75 Gbps, Deep Color, and HD lossless audio formats.
  • Page 15 On-screen menus — Allows for easy system setup using the front panel controls. Key • parameters such as input and output video formats and resolutions are grouped on the initial Quick Setup submenu, while additional submenus provide full control over other functions and settings.

  • Page 16: Control Methods

    Control Methods Control the scalers using one or more of the following methods: The front panel controls and the on-screen display (OSD) menu (see On-Screen • Display (OSD) Menu System on page 25). • A computer, a touch screen panel, or any other device that sends and receives serial communications through the USB, RS-232, or Ethernet port.

  • Page 17: Installation

    Installation This section contains information on how to connect cables to the IN1606 and IN1608 Series models. Topics in this section include: • IN1606 and IN1608 Series Connector Overview • Installation Overview Rear Panel Connections • • Connection Details IN1606 and IN1608 Series Connector Overview IN1606 The IN1606 (see figure 3) features four HDMI and two universal analog video inputs along with stereo balanced or unbalanced audio connectors for each input.
  • Page 18 IN1608 amplifier models The IN1608 amplifier models (see figure 5) feature all the connectors of the IN1608 plus an amplified audio connector. The SA models feature a 4-pole captive screw connector while the MA models feature a 2-pole captive screw connector for amplified audio output. IN1608 SA AMPLIFIED OUTPUT 2x25W(8Ω)/2x50W(4Ω)

  • Page 19: Installation Overview

    Installation Overview Turn off or disconnect all related equipment. Ensure that video sources and output displays are all turned off and disconnected from the power source. Mount the scaler (see Mounting on page 123). Connect input sources (see Power and Input Connections on page 14).

  • Page 20: Power And Input Connections

    Power and Input Connections IN1608 SA AMPLIFIED OUTPUT 2x25W(8Ω)/2x50W(4Ω) INPUTS OUTPUTS AUDIO INPUTS OUTPUTS OVER DTP RS-232 CLASS 2 WIRING REMOTE Tx Rx Tx Rx +48V LINK LINK LINK CONFIGURABLE OVER DTP OVER DTP MIC/LINE VARIABLE 100-240V ~ -- A MAX HDMI HDMI RESET...
  • Page 21 ATTENTION: • Do not connect these connectors to a computer or telecommunications network. • Ne connectez pas ces ports à des données informatiques ou à un réseau de télécommunications. • DTP remote power is intended for indoor use only. No part of the network that uses DTP remote power should be routed outdoors.

  • Page 22: Output Connections

    Output Connections IN1608 SA AMPLIFIED OUTPUT 2x25W(8Ω)/2x50W(4Ω) INPUTS OUTPUTS AUDIO INPUTS OUTPUTS OVER DTP RS-232 CLASS 2 WIRING REMOTE Tx Rx Tx Rx +48V LINK LINK LINK CONFIGURABLE OVER DTP OVER DTP MIC/LINE VARIABLE 100-240V ~ -- A MAX HDMI HDMI RESET HDMI...

  • Page 23: Control Connections

    RS-232 Over DTP port or RS-232 Over HDBT port — To pass bidirectional serial control, connect a control device to the 5-pole captive screw connector. This port includes only the 3 poles labeled “RS-232.” IR Over DTP port or IR Over HDBT port — To transmit and receive IR signals, connect a control device to the 5-pole captive screw connector.

  • Page 24: Ipcp Pro 350 Control Processor Connections

    LAN connector — Connect a computer network to this RJ-45 connector (see figure on page 17). Use a patch cable to connect to a switch, hub, or router. Wire the connector as shown below. Pins: T568A T568B 12345678 Wire Color Wire Color White-green White-orange...

  • Page 25: Connection Details

    Connection Details Analog Video Connection Pinout Table for 15-pin HD Connectors RGBHV RGBs RGBcvS Component S-video Composite Green Green Green Luma Video Blue Blue Blue Chroma H Sync Return C Sync Return Sync Return Red Return Red Return R-Y Return Green Return Green Return Y Return...

  • Page 26: Analog Audio Connection

    Analog Audio Connection Wire the audio input and output connectors as shown in figure 16. Use the supplied tie wrap to strap the audio cable to the extended tail of the connector. This does not apply to the amplified audio output connector on the SA and MA models. No Ground Here Ring Sleeves...

  • Page 27: Hdmi Connections

    HDMI Connections Use an Extron LockIt lacing bracket to secure an HDMI cable to the device. The bracket can be used in a side or stacked formation, as shown below. Side Mounted Stacked Figure 17. LockIt Lacing Bracket Mounting Options Plug the HDMI cables into the panel connection (see of the image below and to the right).

  • Page 28: Twisted Pair Recommendations For Dtp And Hdbaset Communication

    Twisted Pair Recommendations for DTP and HDBaseT Communication Use the following pin configurations for shielded twisted pair cables used for DTP or HDBaseT communication. T568B Pins: 12345678 Wire Color White-orange Orange White-green Blue White-blue Green Insert Twisted Pair Wires White-brown RJ-45 Brown Connector...

  • Page 29: Operation

    Operation This section contains information on the front panel operation, on-screen display menu system, and reset modes of the scalers. Topics in this section include: Front Panel Overview • • Powering Up • Input Selection On-Screen Display (OSD) Menu System •...

  • Page 30: Powering Up

    Input and output LED indicators The number of input and output LED indicators (see figure on page 23) depends on the scaler model. Input signal LEDs — Light for each input when active video content is detected. Output signal LEDs — Light green when active video is being output or blink amber when video output and sync are disabled from the scaler.

  • Page 31: On-Screen Display (Osd) Menu System

    On-Screen Display (OSD) Menu System The OSD menu is used primarily for the initial setup of the device (for other methods of control, see Control Methods on page 10). The OSD menu presents configuration options on a local monitor and can be adjusted with front panel controls. NOTE: The OSD menu has a fixed time-out of 60 seconds.
  • Page 32 To open the OSD menu: Connect a display device to an HDMI output connector (see figure on page 16). Press the button to open the OSD menu. Menu Enter To navigate the OSD menu: Press the button to navigate the nine submenus. The table on page 25 Down...

  • Page 33: Quick Setup Submenu

    Quick Setup Submenu Figure 20. Quick Setup Submenu (IN1608) submenu provides quick access to common input, output, and Quick Setup communication settings. This submenu contains the following submenu items: Auto-Image — Press the button to automatically size and position the current input Enter Auto-Image (see...

  • Page 34: User Presets Submenu

    User Presets Submenu Figure 21. User Presets Submenu (IN1608) submenu manages user presets only (input presets are not available User Presets through the OSD menu). User presets save the current picture control settings for the selected input for recall later or copy settings to other inputs. There are 16 user presets available per input.

  • Page 35: Picture Controls Submenu

    Picture Controls Submenu Figure 22. Picture Controls Submenu (IN1608) submenu adjusts picture settings. Picture Controls Image Position — Press the buttons to select the horizontal (H) or Left Right vertical (V) position of the image. Press the buttons to adjust the value of the Down selected position.

  • Page 36: Input Submenu

    Input Submenu Figure 23. Input Submenu (IN1608) submenu adjusts the active input. Input Auto-Image — Press the button to execute an Auto-Image on the active input. Enter Auto-Image updates active pixel, active lines, horizontal and vertical start, phase, horizontal and vertical image position, and horizontal and vertical image size settings. For analog video sources with dark backgrounds or borders, adjust the Auto-Image threshold with SIS commands (see Auto-Image threshold value...
  • Page 37 Input Format — Press the navigation buttons to select an analog video input format for inputs 1 and 2. All other inputs are digital inputs for HDMI or DVI input signals. The following table shows the available formats for each input. Input 1 Input 2 Input 3...

  • Page 38: Output Submenu

    Output Submenu Figure 24. Output Submenu (IN1608) submenu configures the output resolution, refresh rate, HDMI format, and Output HDCP notification. IN1606 and IN1608 Series Scaling Presentation Switcher • Operation...
  • Page 39 Resolution — Press the navigation buttons to change the resolution and refresh rate from the select list. The following table shows the available resolution and refresh rates. Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz 75 Hz 640x480 800x600...

  • Page 40: Audio Submenu

    Audio Submenu Figure 25. Audio Submenu (IN1608) submenu allows users to adjust audio settings. Extron recommends using the Audio PCS or the internal Web pages for initial audio configuration (see Audio Configuration Page on page 96 for more audio configuration details and tips). Audio Mute —...

  • Page 41: Advanced Submenu

    Gain — Press the navigation buttons to set the gain (in dB) for the active analog or LPCM-2Ch input. Mic/Line Gain and Phantom — After selecting from the Mic/Line 1 Mic/Line 2 list of submenu items, press the buttons to select the Mic/Line gain or Left Right phantom power status.
  • Page 42 Test Pattern — Press the navigation buttons to select a test pattern to display or to turn off a test pattern. The available test patterns are Crop Alternating Pixels Color Bars , and (pink noise). The default setting is Grayscale Blue Mode Audio Test Figure 27.
  • Page 43 Auto Memory — Press the navigation buttons to turn Auto Memory on or off for each input. The scaler stores 32 auto memories per input, with input configuration and picture control data for each video resolution. The default setting enables these memories to automatically recall input and picture controls for previously applied signals.

  • Page 44: Communication Submenu

    Communication Submenu Figure 28. Communication Submenu (IN1608) submenu displays RS-232 settings, current IP configuration (DHCP Communication mode, IP address, Subnet mask, and Gateway address), and MAC address. Press and hold the button for 10 seconds to edit the submenu items listed below. Enter Remote Port —...

  • Page 45: Device Info Submenu

    Device Info Submenu Figure 29. Device Info Submenu (IN1608) submenu displays device information including unit name, firmware Device Info version, internal temperature, input and output signal information, and detected display information. This submenu does not contain any adjustable submenu items. Front Panel Lockout (Executive Modes) The scalers have three modes of front panel security lock that limit the operation of the device from the front panel.

  • Page 46: Reset Modes

    Reset Modes AMPLIFIED OUTPUT 2x25W(8Ω)/2x50W(4Ω) OUTPUTS There are three reset modes (numbered 1, 4, and 5). These are available by pressing the recessed button on the rear panel Reset CLASS 2 WIRING REMOTE (see in the image to the right). See the following table for a VARIABLE RESET RS-232...

  • Page 47: Sis Configuration And Control

    The copyright message is displayed upon connecting to a scaler via TCP/IP or Telnet or after a power cycle via RS-232 and depends on the scaler model. © Copyright YYYY, Extron Electronics, [model], Vx.xx, 60-XXXX-XX (day, date, and time as in...

  • Page 48: Password Information

    Password Information prompt requires a password (administrator level or user level) followed Password: by a carriage return. The prompt is repeated if the correct password is not entered. If the correct password is entered, the unit responds with Login Administrator , depending on password entered.

  • Page 49: Sis Overview

    SIS Overview Using the Command and Response Tables Command and Response Tables for SIS commands beginning on page 48 lists the commands that the scaler recognizes as valid, the responses that are returned to the host, a description of the command function or the results of executing the command, and examples of commands in ASCII (Telnet) and URL encoded (Web).
  • Page 50 X& = Active pixels of the default value ±512 = Active lines of the default value ±256 = Enable or disable = off or disabled = on or enabled = Input standard = no signal detected on the current input = NTSC 3.85 = PAL = NTSC 4.43...
  • Page 51 X2& = Screen saver mode = black output (default) = blue output = Video output mute = unmute = mute video = mute video and sync = Auto-Image threshold value (where = black and = white; 0-100 = default) = HDCP status = no sink or source device detected = sink or source detected with HDCP = sink or source detected but no HDCP...
  • Page 52 = Volume group number = program volume = mic volume = variable volume X4& = Group volume level , where dB or -1000 -1000 -100 0% volume and = 0 dB or 100% volume = Mute group number = program mute = mic mute = output mute = Bass and treble group...
  • Page 53 = HDCP mode = follow the input (default) = always encrypt HDMI outputs = follow the input with continuous DVI trials = always encrypt the HDMI outputs with continuous DVI trials = EDID emulation or output = automatic (matches the current output rate resolution;...

  • Page 54: Command And Response Tables

    Command and Response Tables Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Input Switching Commands Input selection Video and audio X! • Select video and audio from input Video only X! • Select video-only from input &...

  • Page 55: Input Configuration Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Input Configuration Commands Input video format Set video format Set input to format View set format View the video format. Input EDID Assign EDID to input X6)] Assign EDID to input EDID EdidA...
  • Page 56 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Auto-Image Enable Activate Auto-Image for input Disable Turn off Auto-Image for input View View the Auto-Image setting for input Execute Execute an Auto-Image for the Img0 current input (follows the aspect ratio of the current input).
  • Page 57 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Pixel phase (available only for RGB and YUV-HD input signals) Specify a value E X% Set the pixel phase to on the current input. PHAS Phas Increment value Increase the pixel phase by one on the current +PHAS Phas...

  • Page 58: Picture Adjustment Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Picture Adjustment Commands Video mute (defaults to unmuted after a power cycle) Mute output video Mute video only on output Mute output sync and video Mute sync and video on output Unmute output Umute the output View output mute status...
  • Page 59 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Detail filter Specify a value Set the detail filter for the current input E X1% X1%] HDET Hdet Increment value Increase the detail by one. X1%] +HDET Hdet Decrement value Decrease the detail by one.

  • Page 60: Output Configuration Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Output Configuration Commands Output scaler rate Set output rate E X6) X6)] Set the output resolution and rate to RATE Rate View output rate X6)] View the selected output rate. RATE HDMI output format Set format...

  • Page 61: Audio Configuration Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Audio Configuration Commands Audio input format NOTE: For audio input format details, see Audio format on page 97. Set audio input format X3%] Set the audio format of input AFMT AfmtI View audio input format...
  • Page 62 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Volume knob assignment Set volume knob group Set the front panel Volume knob X5^] KNOB Knob1* value to affect group View volume knob group View the volume knob group. X5^] 1KNOB Group volume...

  • Page 63: Preset Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Preset Commands Presets Recall user preset X2!] Recall user preset 1Rpr Save user preset X2!] Save the current picture controls. 1Spr Delete user preset X2!] Clear user preset PRST PrstX1* Recall input preset...

  • Page 64: Advanced Configuration Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Advanced Configuration Commands Test pattern Set pattern E X2) X2)] Set test pattern TEST Test View test pattern X2)] View the current test pattern. TEST Freeze Enable Freeze the current input. Frz1 Disable Unfreeze the current input.
  • Page 65 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Overscan mode (applies only to SMPTE input resolutions) Set value E X# X2%] Set the overscan value to OSCN Oscn View status View the overscan setting. E X# X2%] OSCN HDCP notification (displayed on non-HDCP displays with HDCP input selected)
  • Page 66 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) HDCP mode (valid for HDMI outputs only) Set HDCP mode X5(] Set the HDCP mode to HDCP Hdcp S View HDCP mode View the HDCP mode. X5(] SHDCP setting X5(] Verbose modes 2 and 3...

  • Page 67: Device Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Device Commands On-screen input “bug” time-out NOTE: The OSD bug is a floating message displayed after selecting a new input. Set OSD bug time-out Set the duration the OSD bug E X2# X2#] MDUR...
  • Page 68 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Information request General Information X! • X! • X# • X1) • X2* • X1# • X1#] Query firmware version View firmware version. x.xx Query full firmware version View full firmware version.

  • Page 69: Ip Control Port Commands

    Command ASCII Command Response Additional Description (host to scaler) (scaler to host) IP Control Port Commands IP setup NOTE: Changes made to any TCP/IP settings do not take effect until the reboot networking command ) is issued. 2BOOT Set IP address E X4) •...
  • Page 70 Command ASCII Command Response Additional Description (host to scaler) (scaler to host) Passwords NOTE: Passwords may be hidden (for example, ) on certain host devices. ****** Set administrator password E X5@ X5@] Set the administrator password to • Read administrator X5@] View the administrator password.

  • Page 71: Configuration Software

    Configuration Software The Extron Product Configuration Software (PCS) offers another way to control the scalers via USB, or TCP/IP connection. The graphical interface includes the same functions as those on the device front panel with additional features that are available only through the software.

  • Page 72: Pcs Product Page

    On the Extron website, select the tab (see figure on page 65). Download From the left sidebar, click the link (see figure on page 65). Software TIP: If PCS is featured in the left sidebar, click the link to go directly to the product page (see PCS Product Page below).

  • Page 73: Software Connection

    In the field (see figure on page 66), type “ .” A drop-down menu of Search selected search results appears under the field. Press <Enter> on the keyboard or select from the drop-down menu. Click the button (see figure Download Submit any required information to start the download.

  • Page 74: Device Discovery Panel

    Device Discovery Panel panel displays accessible Extron devices connected directly to Device Discovery the PC or to a LAN or WAN. Devices are identified and sorted by model, IP address, device name, or connection method. Figure 35. Device Discovery Panel To sort the list of available devices: Click the tab (see figure 35,...

  • Page 75: Tcp/Ip Panel

    TCP/IP Panel panel connects PCS to a specific device through Ethernet. TCP/IP Figure 36. TCP/IP Panel Click the tab (see figure 36, TCP/IP In the field ( ), enter the IP address of the desired device. IP Address If required, enter the device password in the field ( Password NOTE: Select the...

  • Page 76: Offline Device Preview

    Offline Device Preview Opening a new device tab for an offline device displays the interface and confirguration options for the chosen model without connecting to it. However, settings cannot be changed. To open a scaler device tab: In the drop-down menu, select .

  • Page 77: Software Overview

    Software Overview Internal Web Pages NOTE: For specific software features, see on page 83 or open the IN1606 and IN1608 Series Product Configuration Software Help file. Figure 39. Online Device Tab (IN1608) Each device tab has a drop-down menu for configuration options. The Device Software menu contains software configuration and information options.
  • Page 78 Show Expanded Device Tabs This option displays the device IP address or connection method in the tab. Device From the menu, select Software Show Expanded Device Tabs Figure 41. Expanded Device Tab (IN1608 Connected through USB) Software Settings This option resets all disabled confirmation dialogs to the default settings. From the , select .
  • Page 79 About Extron PCS This option contains information about the current PCS version. From the menu, select . The Software About Extron PCS About - Extron PCS dialog box opens. Figure 43. About - Extron PCS Dialog Box Click the button for more information. Details Click the button to close the dialog box.

  • Page 80: Device Menu

    Device Menu drop-down menu contains options pertaining to device connection, Device configuration, and information. Figure 45. Device Menu (IN1608) Disconnect This option disconnects the PCS program from the connected device and closes the device tab. From the drop-down menu, select Device Disconnect NOTE: If a device is already disconnected, the...

  • Page 81: Hardware Settings

    Settings Hardware Settings This option displays device information or changes the device name, internal clock, and password of the connected device. From the drop-down menu, select . The Device Settings > Hardware Settings... dialog box opens. For configuration details, see Hardware Pages Hardware Settings page 115.

  • Page 82: Communication Settings

    Communication Settings This option changes communication settings of the connected device. From the drop-down menu, select Device Settings > Communication Settings... dialog box opens. For configuration details, see Communication Settings Communication Settings Page on page 117. Figure 47. Communication Settings Dialog Box Click the button to accept pending changes.
  • Page 83 Backup This option exports all audio, video, and communication settings of the connected device to the PC. This exported configuration can be saved as a backup, or be used to replicate settings from one device to other devices of the same model. When restoring a configuration, specific device settings can be selected.
  • Page 84 Select the file and click the button. The window closes. Open Open Backup File NOTE: Valid configuration files have a .extz file extension. If desired, select the check box to include Include Communication Settings communication settings to the restored configuration. Click the button to apply the saved configuration settings.
  • Page 85 Add target devices to the Device List in any of the following ways: In the  panel (see figure on page 78), enter the necessary • TCP/IP information for the target device in the , and fields IP Address Password Telnet and click the button.
  • Page 86 Update Firmware The update firmware options upload firmware from the host device to the connected device or multiple devices. NOTE: If necessary, download new firmware from the Extron website (see Downloading Updated Firmware on page 125). Figure 53. Update Firmware Options Update Firmware this Device...
  • Page 87 Update Firmware to Multiple Devices... option uploads firmware to multiple Upload Firmware to Multiple Devices devices on the network. NOTE: The connected devices must be connected via LAN. From the drop-down menu, select Device Update Firmware > Update Firmware to .
  • Page 88 To open a previously saved device list: Click the button ( ). The window opens. Open Device List... Open Device List Navigate to the location of the saved device list file and select it. Click the button. The window closes. Open Open Device List NOTE: Valid files have a .mfst file extension.

  • Page 89: Internal Web Pages

    Internal Web Pages The scalers feature an on-board Web server, displayed as a set of internal Web pages. These pages allow for control and operation of the scaler through a LAN or WAN connection. Use a Web browser to view the pages on a PC connected to the scaler. NOTE: The scaler internal Web pages do not support compatibility mode in Microsoft ®...

  • Page 90: Navigating The Internal Web Pages

    Navigating the Internal Web Pages The internal Web pages open with two main tabs: (see figure Configuration on page 86) and (see figure on page 115). Below the tabs is a global Hardware navigation bar with icons that open various pages for configuration settings and information. Each page is separated into the panel and the individual page.

  • Page 91: Breakaway Audio Check Box

    Breakaway Audio Check Box figure Select the check box (see on page 84) to enable audio Breakaway Audio breakaway. The input buttons separate into two columns: video and audio. In the Video column, click the input button associated with the video to be used. In the Audio column, click the input button associated with the audio to be used.

  • Page 92: Configuration Pages

    Configuration Pages The configuration pages contain options for input and output configuration, EDID management, image settings, image size and position, audio configuration, preset management, and device settings. Figure 58. Global Navigation Bar - Configuration Input and Output Configuration Page Click the icon (see figure 58, ) on the Input/Output Config...

  • Page 93: Aspect Ratio

    Aspect ratio From the drop-down menu (see figure on page 86), select Aspect Ratio Fill Follow — Scales the input signal to fill the entire video output. • Fill • — Follows the signal aspect ratio, with respect to the current output resolution Follow setting.

  • Page 94: Output Formats

    Output Configuration panel panel contains controls for output resolution and rate, format Output Configuration settings, switch transitions, and available test pattern selection. Figure 60. Output Configuration (IN1608) Resolution From the drop-down menu (see figure 60, ), select the applicable output Resolution resolution.

  • Page 95: Edid Minder Page

    EDID Minder Page EDID Minder is a management process that manages the EDID information between the scaler and one or more input sources. Click the icon (see figure EDID Minder page 86) on the to open the page. Global Navigation Bar EDID Minder Figure 62.
  • Page 96 EDID filters Use the tab to limit the number of available EDID displayed in the Filter Available panes. EDIDs Connected Outputs From the drop-down menu (see figure on page 89), select a Resolution specific resolution or From the drop-down menu ( ), select a specific refresh rate or Refresh Rate EDID assignment...

  • Page 97: Image Settings Page

    Image Settings Page page adjusts signal sampling and picture control settings, saves and Image Settings recalls user and input presets, and applies overscan settings. Click the Image Settings icon (see figure on page 86) on the to open the Global Navigation Bar Image page.
  • Page 98 Picture Controls panel panel shows adjustable image settings for the selected input. Picture Controls Figure 65. Picture Controls Panel To adjust the picture settings, click and drag the associated slider for any image setting (brightness, contrast, color, tint, or detail) to the desired value. Alternatively, enter a value within the field associated with the image setting, or click the arrows to change the value in the field.
  • Page 99 Presets panel Presets save output settings to be recalled through RS-232, USB, or Ethernet (see the following table for a comparison of saved settings for input and user presets). Settings Included Within Presets Setting User Preset Input Preset Horizontal and Vertical Start Active Lines Pixel Phase Active Pixels...
  • Page 100 To save a preset: From the list (see figure on page 93) or the Input Presets User Presets list ( ), select the desired preset. Click the button ( ) in the same panel as the selected preset. If Save Preset the selected preset already has stored information on it, the dialog box opens.

  • Page 101: Size And Position Page

    Size and Position Page page provides three methods of adjusting image output size and Size and Position position: graphically, numerically, or automatically with Auto-Image. Click the Size and icon (see figure on page 86) on the to open Position Global Navigation Bar page.

  • Page 102: Audio Configuration Page

    Audio Configuration Page From the page, audio inputs and outputs are configured and mixed. Audio Configuration Click the icon (see figure on page 86) on the Audio Config Global Navigation to open this page. There are four tabs for adjusting program and microphone inputs, mixing inputs, and configuring outputs.
  • Page 103 Line input configuration tab contains options to set the audio input format for each input and Line Input adjust the input gain for analog inputs. Figure 70. Line Input Tab (IN1608) Audio format The audio input format specifies whether the audio input is analog, digital, or not to be sent to the output.

  • Page 104: Input Gain

    To select an audio format: Click the tab (see figure on page 97). Line Input From the drop-down menu ( ) of the each input, select the desired Audio Format format. Input gain fader can apply to analog or digital gain depending on the input. It has Input Gain a gain range of -18 dB to +24 dB.
  • Page 105 To optimize input gain with pink noise: Click the tab (see figure on page 97). Line Input For the Web pages only, select the check box ( Enable Meters NOTE: Meters are automatically enabled on the PCS. Set the input gain so the meters read approximately -20 dBFS. If the audio source has an output level setting control, set the output of the player to the maximum or 0 dB of attenuation.

  • Page 106: Phantom Power

    Phantom power Phantom power adds +48 VDC to the mic/line input. The default level for the microphone input is 0 dB, muted. Having the input muted before plugging in a microphone and especially before turning on phantom power is recommended. ATTENTION: •...
  • Page 107 Mic/line gain The mic/line fader has a gain range of -18 dB to +60 dB. Adjustments increase or Gain decrease in 0.1 dB increments. The default setting is 0.0 dB. The gain range accommodates a line level signal, typically from line level source devices or a wireless microphone receiver with a line level output, or a mic level signal from dynamic or condenser microphones.
  • Page 108 Ducking parameters Ducking lowers the level of microphone or program material (based on a source signal from another microphone) for the duration of the signal that is present at the source microphone. It restores the original level after the source signal ceases and after the hold and release times are met.
  • Page 109 Audio mix configuration After the audio inputs have been properly configured, select the tab (see Mix Controls figure 72, ) to mix microphone levels, create a mix of the microphone and program volume, and set bass and treble settings. Figure 72. Mix Controls Tab Mic mix levels Mic mix levels adjust the individual mic levels to create a proper blend (mix) of the two...
  • Page 110 Mic volume Mic volume adjusts the listening level of the mic mix (the blend of the individual microphones) while maintaining the relative individual levels (see Mic mix levels page 103). The Mic Volume fader has a range of -100 dB to 0 dB. It also includes soft limit handles to adjust the minimum and maximum allowable range (highlighted in blue).
  • Page 111 To adjust individual output gain: Click the button (see figure on page 103). The Program Volume Offsets panel appears below the panel. Program Offsets Group Controls Adjust the level of each desired output in any of the following methods ( Click and drag the fader handle to the desired level.

  • Page 112: Output Configuration

    Bass and treble Also known as shelving or tone controls, the bass and treble faders provide the ability to cut or boost levels. Both faders have a range of -24 dB to +12 dB. They also includes soft limit handles to adjust the minimum and maximum allowable range (highlighted in blue). The bass tone control corner frequency is 100 Hz.
  • Page 113 Figure 75. Analog Audio Output 1/2 Section Figure 76. Variable Analog Audio Output Section Figure 77. Digital Audio Output Section (IN1608 Series) The digital output section displays the detected audio format sent to the HDMI or twisted pair output (see Audio format on page 97).
  • Page 114 Release time — Restores the output signal level to normal (unprocessed) levels when • the signal level remains below the threshold level for 100 ms. Ratio — Reduces the signal level at a 100:1 ratio when the limiter is activated. •...
  • Page 115 For the variable analog output: Click the tab (see figure on page 96). Output If desired, deselect the check box (see figure on page 107) to not Mic/Line include the mic/line inputs in the amplified output (this is selected by default). In the panel (see figure...
  • Page 116 Group masters The IN1606 and IN1608 Series include eight pre-configured group masters that allow multiple group members to be adjusted using a single group master control (see the table below for a description of each group master and the associated group members). Group masters provide a convenient way to adjust multiple controls simultaneously.
  • Page 117 Figure 78. Configure Groups Dialog Box To configure the groups: Click the tab (see figure on page 103). Mix Controls In the panel, click the button (see figure Group Controls Configure Groups dialog box opens. Configure Groups For the desired group master, click the corresponding drop-down menu (see figure 78, ) to display a list of available group members.

  • Page 118: Preset Management Page

    Preset Management Page page gives access to input and user presets. Click the Preset Management Preset icon (see figure on page 86) on the to open Management Global Navigation Bar page. Preset Management Figure 79. Preset Management Page To save a preset: Select the input preset or user preset (see figure 79, ) to store the current configuration.

  • Page 119: Device Settings Page

    To clear a preset: Select the input preset or user preset (see figure on page 112) to be cleared. figure Click the button (see ) located in the same section of the screen. A Clear confirmation dialog box opens. Click the button to erase saved data or click the button to return to the Clear...
  • Page 120 Select a duration to display the screen saver before the output sync is disabled. Select the check box to disable the scaler output sync after • Disable Sync After a set duration without an active input. When selected, the Duration On Screen field becomes available.

  • Page 121: Hardware Pages

    Hardware Pages pages contain unit information and options for device naming, Hardware communication settings, updating firmware, executive and power modes, date and time settings, passwords, and reset modes. Click the tab (see figure 81, ) to open Hardware these pages. Figure 81.

  • Page 122: Device Name Page

    Device Name Page page allows users to assign or change the name or hostname of the Device Name connected device. Click the icon (see figure on page 115) on the Device Name to open this page. Global Navigation Bar Figure 83. Device Name Page NOTE: The device name is used as the hostname of the scaler.

  • Page 123: Communication Settings Page

    Communication Settings Page page contains options to adjust device settings for Communication Settings RS-232 and Ethernet connections. Click the icon (see Communication Settings figure on page 115) on the to open the page. Global Navigation Bar Figure 84. Communication Settings Page RS-232 settings From the drop-down menu (see figure 84,...

  • Page 124: Update Firmware Page

    Update Firmware Page page provides a means of uploading firmware files to the connected Firmware Loader scaler. Click the icon (see figure on page 115) on the Update Firmware Global to open this page. Navigation Bar Figure 85. Update Firmware Page If necessary, download firmware updates from www.extron.com.

  • Page 125: Executive And Power Mode Page

    Executive and Power Mode Page page contains options for enabling or disabling the front Executive and Power Mode panel lockout and power modes. Click the icon (see figure Exec/Power Mode page 115) on the to open the page. Global Navigation Bar Figure 86.

  • Page 126: Date And Time Page

    Date and Time Page page contains adjustable device date and time settings. Click the Date and Time Date icon (see figure on page 115) on the to open and Time Global Navigation Bar the page. Figure 87. Date and Time Page To automatically sync the date and time to a connected PC: Click the button (see figure 87,...

  • Page 127: Password Page

    Password Page page allows the user to set an administrator and user password on Password the device. Click the icon (see figure on page 115) on the Password Global to open the page. Navigation Bar Figure 88. Password Page Administrators and users can view all settings on the device. Administrators have the ability to make adjustments to any setting.

  • Page 128: Reset Device Page

    Reset Device Page page allows the user to reset the device. Click on the Reset Device Reset Device icon (see figure on page 115) on the to open the page. Global Navigation Bar Figure 89. Reset Device Page There are three reset options: Reset Device Settings (Retains TCP/IP Settings) —...

  • Page 129: Reference Information

    Reference Information This section provides reference or supplemental information. Topics in this section include: Mounting • • Downloading Updated Firmware Mounting Tabletop Mounting Attach the provided rubber feet to the bottom four corners of the enclosure. Rack Mounting Mount the scalers into racks with the pre-installed rack ears (see UL Guidelines for rack mounted devices on page 124).

  • Page 130: Furniture Mounting

    UL Guidelines for rack mounted devices The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the scaler in a rack. Elevated operating ambient temperature — If the equipment is installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient temperature.

  • Page 131: Downloading Updated Firmware

    Downloading Updated Firmware Figure 93. Downloading Firmware from the Extron Website On the Extron website, click the tab (see figure 93, Download From the left sidebar, click the link ( Firmware Navigate to the IN1606 or IN1608 model ( Ensure the available firmware version is a later version than the current one on the device.
  • Page 132 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
