Group Masters
The following is a list of groups for Application 2. Groups are created and ordered in this
fashion so that mute groups aligns vertically with the corresponding gain group that controls
volume.
Group Name Group
Number
Program (fader)
Program (mute)
Far End (fader)
Far End (mute)
Privacy Mute
Figure 88. Application 2 Group Controls
MediaPort 200 • with External DSP with AEC Application Setup
Description
2 Volume control for program audio to local room
13 Mute control for program audio to local room
3 Volume control for far end audio (from MediaPort) to
local room
14 Mute control for far end audio (from MediaPort) to local
room
12 Mutes local mics for private discussion
107
