Command

Advanced Configuration

Test Pattern
X2#
NOTE: can be entered as a single digit, but is always returned as a 2 digit number.
Set test pattern
View test pattern
No Signal Logo
Select image file
View selected image
Freeze
Enable
Disable
View
NOTES:
X1) = Freeze status:
X2# = Test patterns: 0 = Off (default), 1 = Crop, 2 = Alternating pixels, 3 = Crosshatch,
4 = Color bars, 5 = Grayscale
The response is two digits padded with a zero.
X3% = String: filename.
ASCII Command
(host to unit)
E X2# }
TEST
E }
TEST
E X3% }
A1, LOGO
E }
A1LOGO
1F
0F
F
= off, = on
0 1
Response
(unit to host)
X2#]
Test
X2#]
With tagged responses
(verbose modes 2 and 3):
X2#]
Test
X3%]
LogoA1,
X3%]
With tagged responses
(verbose modes 2 and 3):
X3%]
LogoA1,
]
Frz1
]
Frz0
X1)]
With tagged responses
(verbose modes 2 and 3):
X1)]
Frz
MediaPort 200 • Remote Configuration and Control
Additional Description
X2#
Select test pattern .
View the current test
pattern.
Assign an uploaded image
file as the screensaver
(displayed with no active
HDMI input).
View the file name of the
current user-assigned logo.
Freeze the input.
Unfreeze the input.
View the freeze status of
the input.
129
