MediaPort 200 with
External DSP with
AEC Application
Setup
The MediaPort 200 can integrate seamlessly into a variety of applications. This section
contains instructions on how to set up the MediaPort 200 for the following applications:
•
•
These applications include suggestions for specific inputs and outputs for use with the
Extron DMP 128 C Digital Matrix Processor models, including DMP 128 C AT, DMP 128 C P,
and DMP 128 C P AT as the external DSP matrix processor (referred to in this section as
DSP or external DSP with AEC).
Additionally, DSP Configurator template files with the routing and configurations described
are available for use with DMP 128 C model products and can be downloaded from
the
integration of the MediaPort 200 with DMP 128 C model products.

Overview

This section contains a general discussion of MediaPort 200 inputs and outputs and their
intended uses when used in conjunction with an external DSP with AEC. All of the principles
described here are used in the application setup procedures that follow.
NOTE: Ensure that the MediaPort 200 is set to External DSP with AEC audio mode

Video Input and Output

HDMI Input

The HDMI Input can be fed from a camera, a computer, HDMI switcher, or other HDMI
source. The HDMI source can be a video conference or document camera without audio.
It can also be another program source such as a PC or switcher output that includes
embedded audio. If the HDMI input is fed with a camera that includes microphone audio,
the HDMI audio input should be muted.
Application 1
— MediaPort 200 with external DSP with AEC
Application 2 — MediaPort 200 with external DSP with AEC with hard and soft video
codecs
DMP 128 Web page. These preconfigured files facilitate and greatly simplify the
in PCS before beginning setup (see
information about selecting Standalone audio mode).
MediaPort 200 • with External DSP with AEC Application Setup
General Settings Tab on page 59 for more
93
