Protection; Control - Deif Multi-line 2 Designers Reference Handbook

AGC
1010 Reverse power
No. Setting
1011 Reverse power
1012 Reverse power
1013 Reverse power
1014 Reverse power
1015 Reverse power
1016 Reverse power
1020 Overcurrent 1
No. Setting
1021 Overcurrent 1
1022 Overcurrent 1
1023 Overcurrent 1
1024 Overcurrent 1
1025 Overcurrent 1
1026 Overcurrent 1
1030 Overcurrent 2
No. Setting
1031 Overcurrent 2
1032 Overcurrent 2
1033 Overcurrent 2
1034 Overcurrent 2
1035 Overcurrent 2
1116 Overcurrent 2
This setup menu consists of the synchronisation setup and the regulation setup.
Synchronisation
2010 Synchronisation type
No. Setting
2011 Sync. type
If dynamic synchronisation is chosen, the next menu will be 2020 Dynamic synchronisation
. If static synchronisation is chosen, the next menu will be 2030 Static synchronisation .
DEIF A/S

Protection

Min.
setting
Setpoint -50.0%
Timer 0.1 s
Relay output A R0 (none)
Relay output B R0 (none)
Enable OFF
Fail class Alarm (1)
Min.
setting
Setpoint 50.0%
Timer 0.1 s
Relay output A R0 (none)
Relay output B R0 (none)
Enable OFF
Fail class Alarm (1)
Min.
setting
Setpoint 50.0%
Timer 0.1 s
Relay output A R0 (none)
Relay output B R0 (none)
Enable OFF
Fail class Alarm (1)

Control

Sync. type
Designer's Reference Handbook
Max. Third
setting setting
0.0% -
100.0 s -
Option -
dependent
-
ON RUN
Trip MB (6) -
Max. Third
setting setting
200.0% -
100.0 s -
Option -
dependent -
ON RUN
Trip MB (6) -
Max. Third
setting setting
200.0% -
100.0 s -
Option -
dependent
-
ON RUN
Trip MB (6) -
First setting Second
setting
Static sync. Dynamic
sync.
Factory
setting
-5.0%
10.0 s
R0 (none)
R0 (none)
ON
Trip GB (3)
Factory
setting
115.0%
10.0 s
R0 (none)
R0 (none)
ON
Warning (2)
Factory
setting
120.0%
5.0 s
R0 (none)
R0 (none)
ON
Trip GB (3)
Factory
setting
Dynamic
sync.
Page 150 of 168
