10. Parameter List; Parameter Table Description - Deif Multi-line 2 Designers Reference Handbook

AGC
This chapter includes a complete standard parameter list. Therefore, this part of the handbook is
to be used for reference when specific information about the individual parameters is needed for
the unit setup. An overview list can be seen on the next page.
The parameter lists for the available options are presented in the documents
Description of Options describing the individual options in detail.
The table consists of the following possible adjustments:
Setpoint: The alarm setpoint is adjusted in the setpoint menu. The setting is a percentage
of the nominal values.
Timer: The timer setting is the time that must expire from the alarm level is reached
until the alarm occurs.
Relay output A: A relay can be activated by output A.
Relay output B: A relay can be activated by output B.
Enable: The alarm can be activated or deactivated. ON means always activated, RUN
means that the alarm has run status. This means it is activated when the
running signal is present.
Fail class: When the alarm occurs the unit will react depending on the selected fail class.
Small differences due to the character of the parameters may exist between the
individual tables.
It is also possible to configure the parameters by using the PC utility software. It will be possible
to make the same configurations as described above.
By using the PC utility software some extra functionalities are available. For all the protections it
is possible to make an automatic acknowledgement of the alarm. Usually it is important when
the mains protections are used, as the sequences are blocked until the alarm is acknowledged.
