AGC
Serial connection
The serial connection to the GSM modem is done via a straight cable (option J3) (male/female).
Basic parameter settings
Setting no. Name
GSM GSM PIN code
GSM 12345678901
GSM 12345678901
GSM 12345678901
GSM 12345678901
GSM 12345678901
For calling a foreign number type '+ country code' instead of '00', for example
dial +45 99999999 for a Danish number.
The phone number can only be dialed using the PC utility software.
The SIM card used in the cellular telephone must support data transfer.
PIN code configuration
After each auxiliary supply power up, the unit will send the required PIN code to the modem, if
this is necessary. The PIN code is adjusted in the PC utility software.
It is possible to communicate with the unit via the PC utility software. The purpose is to be able
to remote monitor and control the gen-set application.
It is possible to remote control the gen-set from the PC utility software, if a
modem is used. Take precautions that it is safe to remote operate the gen-set
to avoid personal injury or death.
Serial connection
The serial connection to the GSM modem is via the null-modem cable (option J3).
Setup
The Modbus protocol type can be changed from RTU to ASCII (9020 Service port
) . This menu can only be reached using the JUMP push-button. When set to 1, the ASCII
protocol type is used, and the unit will allow for the slower modem communication.
9020 Service port
No. Setting
9021 Service port
If setting 9020 is set to 1, the PC utility software cannot communicate with the
unit when it is connected directly to the PC and a modem is not used.
DEIF A/S
Function
Set PIN code for GSM modem
Set phone no. for SMS to cellular phone 1
Set phone no. for SMS to cellular phone 2
Set phone no. for SMS to cellular phone 3
Set phone no. for SMS to cellular phone 4
Set phone no. for SMS to cellular phone 5

USW communication

Min. setting
Setpoint 0 (normal USW)
Designer's Reference Handbook
Max. setting Factory setting
1 (modem USW) 0 (normal USW)
Set to
None
None
None
None
None
None
