AGC
Dynamic regulation area
The drawing below shows the dynamic regulation area at given values of KP. The dynamic area
gets smaller, if the KP is adjusted to a higher value.
KP = 10
mA
44
45
DEIF A/S
Dynamic regulation band
30
KP = 1000
20
KP = 100
10
0
46
47
48
49
-10
-20
-30
Frequency
Designer's Reference Handbook
50
51
52
53
54
55
56
Page 127 of 168
