6110 Battery low voltage alarm

No. Setting
6111 Battery low V
6112 Battery low V
6113 Battery low V
6114 Battery low V
6115 Battery low V
The alarm is for the auxiliary power supply measured on terminal 1 and 2.

6120 Battery high voltage alarm

No. Setting
6121 Battery high V
6122 Battery high V
6123 Battery high V
6124 Battery high V
6125 Battery high V
The alarm is for the auxiliary power supply measured on terminals 1 and 2.

6130 Language

No. Setting
6130 Language
6131 Language

6140 Alarm horn

No. Setting
6141 Alarm horn
The setting is the maximum time the horn relay activates at an alarm. If the setting is adjusted to
0 s, the horn relay will be activated continuously until the alarm is acknowledged.

6150 Running status

No. Setting
6151 Run status
6152 Run status
6153 Run status
6154 Run status

6160 Remove starter

No. Setting
6161 Remove starter
6162 Remove starter
DEIF A/S
Setpoint
Timer
Relay output A
Relay output B
Enable
Setpoint
Timer
Relay output A
Relay output B
Enable
Selection display
English
Timer
Timer
Relay output A
Relay output B
Enable
Setpoint
Number of teeth
Designer's Reference Handbook
Min. setting Max. setting
8/15.0V 32.0V
0.0 s 999.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting
12.0V 36.0V
0.0 s 999.0 s
R0 (none) Option
R0 (none) dependent
OFF ON
Setting
-
English
Language 1-11
Min. setting Max. setting
0.0 s 990.0 s
Min. setting Max. setting Factory
0.0 s 300.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting Factory
1 RPM 2000 RPM
0 teeth 500 teeth
Factory
setting
18.0V
1.0 s
R0 (none)
R0 (none)
ON
Factory
setting
30.0V
1.0 s
R0 (none)
R0 (none)
ON
Factory setting
-
English
-
Factory
setting
20.0 s
setting
5.0 s
R0 (none)
R0 (none)
OFF
setting
400 RPM
0 teeth
Page 165 of 168
