AGC
Click here to change the configuration.
It is only possible to configure the view windows via the PC software –
configuration via the display unit is not possible.
The selectable values and measurements are presented in the table on page 59 in this
handbook.
If the text 'no text' is selected in all 3 lines in a window, it will not be displayed. This is to get a
continuous displaying, if a window is not to be used.
There is a maximum of 15 configurable view windows in V1.
DEIF A/S
Designer's Reference Handbook
Page 57 of 168
