AGC
The test sequence will start when the test mode is selected.
Manual
When manual mode is selected, the binary increase/decrease inputs can be used (if they have
been configured) as well as the start and stop push-buttons. When starting in manual mode, the
gen-set will start without any subsequent regulation.
Block
When the block mode is selected, the unit is not able to initiate any sequences, e.g. the start
sequence.
Block mode must be selected, when maintenance work is carried out on the gen-
set.
The following drawings illustrate how the mode selection is carried out.
Pushing the MODE push-button will change the displayed text. After pushing 'MODE', the fourth
display line indicates the selectable modes. In the third display line, the underscored (fourth line)
selection will be displayed.
Two possibilities are now available:
If 'BACK' is pushed, the display returns to the original text without changing the mode.
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SETUP MENU
SETUP V3
G 0 0
f-L1 0.00Hz
PROTECTION SETUP
PROT CTRL
If 'SEL' is pushed, the underlined mode is selected, and the display returns to the original text. In
this example the SEMI-AUTO mode is selected.
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SETUP MENU
SETUP V3
G 0 0
f-L1 0.00Hz
PROTECTION SETUP
PROT CTRL
DEIF A/S

Mode selection

1. push
'MODE'
V2 V1
0V 1. push
'MODE'
I/O SYST
3. push
'MODE'
V2 V1
0V 3. push
'MODE'
I/O SYST
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
or
G 0 0 0V
f-L1 0.00Hz
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
or
G 0 0 0V
f-L1 0.00Hz
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
Designer's Reference Handbook
2. push
'BACK'
2. push
'BACK'
4. push
'SEL'
4. push
'SEL'
