Deif Multi-line 2 Designers Reference Handbook page 131

AGC
Signal length
The signal length is calculated compared to the adjusted period time. In the drawing below the
effect of the proportional regulator is indicated.
1200
1000
800
kP
600
400
200
0
0
In this example we have a 2 percent regulation deviation and an adjusted value of the KP = 200.
The calculated regulator value of the unit is 40%. Now the pulse length can be calculated with a
period time = 2500 ms:
The length of the period time will never be shorter than the adjusted ON time. The P regulator
causes the relay output to activate. The I regulator has the same effect on the relay output as
described on page 126 concerning the reset time t
DEIF A/S
P-regulator
0,5%
20 40
regula tor value
e / 100
DEVIATION
40 / 100 * 2500
Designer's Reference Handbook
60 80
* t
PERIOD
=
1000 ms
.
N
1%
2%
4%
8%
100 120
Page 131 of 168
