AGC
Designer's Reference Handbook
High/low
Start/stop
speed
gen-set
selection
Low speed
input
Idle run input
Relay
AGC
GOVERNOR
Temperature
control input
Actuator
Examples
Idle speed during starting and stopping
In this example both the start and the stop timers are activated.
The start and stop sequences are changed in order to let the gen-set stay at the idle level before
speeding up. It also decreases the speed to the idle level for a specified delay time before
stopping.
RPM
1500
t
t
START
STOP
300
t
Start
Stop
DEIF A/S
Page 87 of 168
