AGC
Event A
Dig. input no. 118
Not Dig. input no. 118
See the M-logic Manual for details.
AOP
M-logic is used when the AOP is used for switching between the two sets of nominal settings.
Select the required AOP push-button among the input events, and select the nominal settings in
the outputs.
Event A
Button07
Button08
See the M-logic Manual for details.
Menu settings
In menu 6025 the switching is made between settings 1 and 2 as described in the table:
Nominal value
Menu setting
OFF
1
2
Both setting 'OFF' and setting '1' will activate the nominal settings 1. The difference will be the
number of available overspeed settings.
The selection OFF (where two overspeed alarms are active) can only be
performed from the display.
Overspeed protection
When fire pump mode is selected with a digital input, then the overspeed alarm menu 4320
(Overspeed 2) is activated. The overspeed alarm menu 4310 is not active!
If the fire pump mode is used with the selection of nominal settings adjusted
to 'OFF', then the overspeed alarm 2 (4320) must be used to protect the engine
from overspeeding. Overspeed 1 (4310) is not active.
DEIF A/S
Event B
or Not used or
or Not used or
Event B
or Not used or
or Not used or
Nominal settings 1
X
X
-
Designer's Reference Handbook
Event C Output
Not used Set nom. parameter settings 1
Not used Set nom. parameter settings 2
Event C Output
Not used Set nom. parameter settings 1
Not used Set nom. parameter settings 2
Nominal settings 2
-
-
X
Available overspeed
protections
4310/4320
4310
4320
