Flowcharts - Deif Multi-line 2 Designers Reference Handbook

AGC
Using flowcharts, the principles of the most important functions will be illustrated in the next
sections. The functions included are:
• Mode shift
• MB open sequence
• GB open sequence
•
Stop sequence
•
Start sequence
•
MB close sequence
•
GB close sequence
•
Fixed power
•
Load take over
•
Island operation
•
Peak shaving
•
Mains power export
•
Automatic Mains Failure
•
Test sequence
The flowcharts below are for guidance only. For illustrative purposes the
flowcharts are simplified in some extent.
