Description of options
Option O1
Water turbine control
Multi-line 2 – version 2
4189340286F
SW version 2.4X.X
• Description of option
• Functional description
• Parameter list
DEIF A/S, Frisenborgvej 33
DK-7800 Skive, Denmark
Tel.: +45 9614 9614, Fax: +45 9614 9615
E-mail: deif@deif.com, URL: www.deif.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Deif Multi-line 2
Summary of Contents for Deif Multi-line 2
- Page 1 Description of options Option O1 Water turbine control Multi-line 2 – version 2 4189340286F SW version 2.4X.X • Description of option • Functional description • Parameter list DEIF A/S, Frisenborgvej 33 Tel.: +45 9614 9614, Fax: +45 9614 9615 DK-7800 Skive, Denmark...
-
Page 2: Table Of Contents
........................ 14 URBINE REGULATION ..........................15 EQUENCES ..........................16 IGITAL NPUT ............................17 NHIBIT PARAMETER LIST ......................19 This manual is valid for standard multi-line 2 PPU/GPC units with firmware version 2.32.0 or later. DEIF A/S Page 2 of 19... -
Page 3: Warnings And Legal Information
Option O1, Water turbine control 1. Warnings and legal information DEIF takes no responsibility for installation or operation of the generator set. If there is any doubt about how to install or operate the generator set controlled by the unit, the company responsible for the installation or the operation of the set must be contacted. -
Page 4: Description Of Option
Input 8 common Common Analogue input 8+ 4-20mA in The 4-20mA input no. 5 must be used for water level input. The 4-20mA inputs no. 6, 7 and 8 can only be used as alarm inputs. DEIF A/S Page 4 of 19... - Page 5 Binary input Optocoupler Start sync./control functions/configurable Binary input Optocoupler Ext. communication control/configurable Binary input Optocoupler Block loss of mains/configurable Com. Common Common for terminals 23-27 Terminal 25 cannot be used for jet deflector feedback. DEIF A/S Page 5 of 19...
-
Page 6: Wiring
Jet Deflector Feedbac k + 24VDC Start Deload Sync / Closed Contr. 23 or 24 or 26 or Sync. Multi-line 2 Relay 4 Open GCB 4...20mA Water Level R elay 1 Speed Up Speed Down Jet Deflectors 67 68 65 66... - Page 7 Jet Deflector Feedback + 24VDC Start Deload Sync / Closed Contr. 23 or 24 or 26 or Sync. Multi-line 2 Relay 4 Open GCB 4...20mA Water Level Relay 1 Jet Deflectors 66 67 66 67 70 71 91 92 95 96...
-
Page 8: Functional Description
Water level control requires a 4-20mA transducer. Turbine operation The turbine can be controlled by the multi-line 2 in five different ways. This depends on the mode selection on the unit. The table shows the running modes depending on the mode setting. - Page 9 This can be adjusted from the USW or from the display. The 4mA value can be adjusted negative. This is to be able to stop the regulation (see the description of ‘Water level regulation’ on page 10). DEIF A/S Page 9 of 19...
-
Page 10: Regulation Principle
Regulation principle Principle When the regulation is started, the multi-line 2 will regulate the power according to the water level and the fixed power set point. The below drawing illustrates how the regulation works: 1. - Page 11 (The purpose of this is partly to avoid the generator to go into reverse power and partly to keep the turbine in the economic operating range.) The operating range of the turbine can be reduced in the high end by decreasing the P (menu 4041) to a lower value. DEIF A/S Page 11 of 19...
-
Page 12: Jet Deflector
The relay used for the jet deflector is the relay 1. (Terminal 5, 6, 7 - see extract from I/O list below). Term. Function Technical Description data Relay 1 Configurable/jet deflector operation Com. 250V AC / 8A DEIF A/S Page 12 of 19... - Page 13 When the deflector must open, relay 1 will change position to 5/6, thus disconnecting the current flow through 6/7. The purpose of using the status relay is to open the deflector whenever the multi-line 2 is without power or when the watch dog of the device detects a fault.
-
Page 14: Turbine Regulation
20mA. At this point, cascade #2 will take over and increase its output until 20mA, and so on. When the turbine is stopped the sequence is reversed. The output sequence looks like this in a situation where all cascades open: DEIF A/S Page 14 of 19... -
Page 15: Sequences
The turbine start function can be used in connection with relay outputs only. This timer represents the time where the speed UP signal is active if no speed is detected during start-up of the turbine. (Running detection is the frequency measurement or pick-up tacho input). DEIF A/S Page 15 of 19... -
Page 16: Digital Input
3. Shut control valves Digital Input The inputs can be configured in the PC utility software. The following function is special for option O1. Input function Input type Const./Pulse Terminal 23, 24, 26, 27 Jet deflector DEIF A/S Page 16 of 19... -
Page 17: Inhibit
USW. Not running When the protections are configured to ‘Not running’, then the alarms are activated when the frequency measurement is f –1Hz, typically 49Hz or 59Hz. NOMINAL DEIF A/S Page 17 of 19... - Page 18 GPC, PPU Option O1, Water turbine control When stopping the turbine, the alarms will not be deactivated before the generator voltage has dropped to 30 % * U NOMINAL DEIF A/S Page 18 of 19...
-
Page 19: Parameter List
4045 Controller settings Water level min. -100% 250% Wmin 4130 Water level indication Setting Min. setting Max. setting Factory setting 4131 Water level in. Enable DEIF A/S reserves the right to change any of the above DEIF A/S Page 19 of 19...
