Deif Multi-line 2 Designers Reference Handbook page 98

AGC
Input function
38 External Q power
39 Print status
40 Print event log
41 MB close inhibit
42 Engine comm.
inhibit
43 Enable mode shift
44 Enable GB black
close
45 Enable sep. sync.
46 Custom alarm
inhibit
47 Start enable
48 GB spring loaded
49 MB spring loaded
Functional description
1. Fire pump
This input deactivates all protections except the overspeed protection and the emergency stop
input. The number of start attempts is 7 by default, but it can be configured in 6180 Start
attempts . Also a special cool down timer is used in the stop sequence after an activation of this
input.
2. Access lock
Activating the access lock input deactivates the control display push-buttons. It will only be
possible to view measurements, alarms and the log.
3. Running feedback
The input is used as a running indication of the engine. When the input is activated, the start
relay is deactivated.
4. Remote start
This input initiates the start sequence of the gen-set when semi-auto or manual mode is
selected.
5. Remote stop
This input initiates the stop sequence of the gen-set when semi-auto or manual mode is
selected. The gen-set will stop without cooling-down.
6. Semi-auto
Changes the present running mode to semi-auto.
7. Test
Changes the present running mode to test.
8. Auto
Changes the present running mode to auto.
9. Manual
Changes the present running mode to manual.
DEIF A/S
Auto Semi Test
X X X
X X X
X X X
X X X
X X X
X
X X X
X X X
X X X
X X X
X X X
X X X
Designer's Reference Handbook
Man Block Configurable
Configurable
Configurable
Configurable
X X Configurable
X X Configurable
Configurable
X X Configurable
X X Configurable
X X Configurable
X NA Configurable
Configurable
Configurable
Input
type
Constant
Pulse
Pulse
Constant
Constant
Constant
Constant
Constant
Constant
Constant
Constant
Constant
Page 98 of 168
