Deif Multi-line 2 Designers Reference Handbook page 170

AGC
9120 Service menu
The service menu can only be entered using the 'JUMP' push-button. This menu is used in
service situations.
In the alarm selection you can see all the alarm timers and their remaining time if they are
counting.
The input and output selections show the present status of the inputs and outputs. E.g. mode
inputs, relay outputs and load sharing lines.
No. Setting
9121 Service menu
9122 Service menu
9123 Service menu
9124 Service menu
9130 Single phase/split phase/three phase
No. Setting
9131 Mode
DEIF A/S
Alarm
Digital input
Digital output
Miscellaneous
Mode
Designer's Reference Handbook
Description
Shows remaining alarm delay time
Shows digital input status
Shows digital output status
Shows miscellaneous information
Description
0 = Three phase system
1 = Split phase system
2 = Single phase system
DEIF A/S reserves the right to change any of the above.
Page 170 of 168
