Operating Environment - Sun Microsystems Netra T4 AC100 Service And System Reference Manual

System unit electronics are contained on a single printed circuit board
(motherboard). The motherboard contains the CPU modules, memory, system
control application-specific integrated circuits (ASICs) and I/O ASICs.
A fully-configured system weighs approximately 27.3 kg (60 lb).

Operating Environment

Solaris 8 Update 4/01 and Update 7/01
Power
Rack mounting enclosure with one single-feed 100 –240 VAC power supply unit
(AC100) or one twin-feed –48 VDC / –60 VDC power supply unit (DC100)
Processors
Support for up to two 750 MHz UltraSPARC III processor modules, each with
8 MByte Ecache
Memory
Support for up to eight 128 MByte-, 256 Mbyte-, 512 MByte- or 1 GByte Next
Generation Dual Inline Memory Module (NG-DIMMS) installed in two groups of
four providing from 512 MByte to 8 GByte of memory
IO
Four PCI 2.1 compliant slots:
1
one long 64/32-bit, 66/33 MHz
1
two long 64/32-bit, 33 MHz
2
one short 64/32-bit, 33 MHz
One 10/100BaseT Ethernet connection
One Fast-Wide SCSI connection
Four USB connections (two twin Series A ports) @ 12 Mb/s
One external FC-AL connection
Two internal FC-AL connections for hard disks
Two RS232/RS423 serial ports
One parallel port
1. Up to 312 mm long
2. Up to 174.6 mm long
Chapter 1 System Description 1-3
