diag-level Variable Set to max (3 of 17)
CODE EXAMPLE E-1
{1}Verify TICK register is counting
{0}* Tick & Tick-Compare Reg
{1}Verify TICK register Overflow
{0}Walk 1/0 TICK Compare register
{1}Verify TICK Interrupt
{0}Verify TICK register is counting
{0}Verify TICK register Overflow
{0}Verify TICK Interrupt
{1}* Stick & Stick-Compare Reg
{1}Walk 1/0 STICK Compare register
{1}Verify STICK register is counting
{0}* Stick & Stick-Compare Reg
{1}Verify STICK register Overflow
{0}Walk 1/0 STICK Compare register
{1}Verify STICK Interrupt
{0}Verify STICK register is counting
{0}Verify STICK register Overflow
{0}Verify STICK Interrupt
{1}* Measure CPU Clock
{0}* Measure CPU Clock
{0}AFT pin is high
{0}Setup Memory Controller
{0}* IMMU Registers
{1}* IMMU Registers
{0}Testing I-TSB
{1}Testing I-TSB
{0}Test walking 1 through the register
{1}Test walking 1 through the register
{0}Test walking 0 through the register
{1}Test walking 0 through the register
{0}Testing I-TLB Tag Access
{1}Testing I-TLB Tag Access
{0}Test walking 1 through the register
{1}Test walking 1 through the register
{0}Test walking 0 through the register
{1}Test walking 0 through the register
{0}* DMMU Registers
{1}* DMMU Registers
{0}Testing Primary Context
{1}Testing Primary Context
{0}Test walking 1 through the register
{1}Test walking 1 through the register
{0}Testing Secondary Context
Appendix E Example POST Diagnostic Output
E-3
