11.1
Parallel Connector
FIGURE 11-2
TABLE 11-1
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
11-2
Netra T4 AC100/DC100 Service and System Reference Manual • August 2001
13
25
DB-25 Parallel Connector
Parallel Connector Pinout
Signal Name
DATA_STROBE_L
DAT(0)
DAT(1)
DAT(2)
DAT(3)
DAT(4)
DAT(5)
DAT(6)
DAT(7)
ACK_L
BSY
PERROR
SELECT_L
AFXN_L
ERROR_L
RESET_L
IN_L
GND
GND
GND
GND
1
14
I/O
Service
Data Strobe (active LOW)
Data Bit 0
Data Bit 1
Data Bit 2
Data Bit 3
Data Bit 4
Data Bit 5
Data Bit 6
Data Bit 7
Acknowledge (active LOW)
Busy (active HIGH)
Paper End (active HIGH)
Select (active LOW)
Auto Line Feed (active LOW)
Error (active LOW)
Initialize Printer (prime active LOW)
Select Input (active LOW)
Ground
Ground
Ground
Ground
