5.7

Front Fascia

The detachable front fascia houses the optional air filter and is fastened to the
system chassis at the bottom edge by two plastic tethers. You need to detach the
fascia completely only to change the filter (to avoid dust from the filter being sucked
back into the system); you can carry out all other procedures by lowering the fascia
and leaving the tethers attached.
Mesh Screen
FIGURE 5-5
5-10 Netra T4 AC100/DC100 Service and System Reference Manual • August 2001
Filter Retainer
Filter
Front Fascia and Filters
Optional
Catch Tether
