Note – In
FIGURE 10-18
Motherboard Component Functions
TABLE 10-8
Designation
J0100
J0101
J0202
J0203
J0304
J0305
J0406
J0407
J0501
J0601
J0701
J0801
J1801
J2001
J2103
J2104
J2202
J2301
J2401
J2501
J2601
J2901
J2902
J3001
J3002
J3202
, unnumbered connectors are not used by the Netra T4 system
Function
DIMM
DIMM
DIMM
DIMM
DIMM
DIMM
DIMM
DIMM
CPU connector
CPU connector
CPU connector
CPU connector
Not used
Serial ports A, B rear panel connector
Jumper PROM R/W
See Section 10.5, "Jumper Descriptions" on page 10-40
Jumper PROM Select
See Section 10.5, "Jumper Descriptions" on page 10-40
SCSI, Parallel rear panel connector
66 MHz PCI 1 connector
33 MHz PCI 2 connector
33 MHz PCI 3 connector
33 MHz PCI 4 connector
FC-AL internal connector
FC-AL rear panel connector
USB rear panel connector
USB rear panel connector
Not used
Chapter 10 Functional Description 10-39
