11
C H A P T E R

External I/O Connectors

This chapter provides information about the external I/O connectors.
FIGURE 11-1
SCCR Parallel Ground
Warning: Power off system before removing
or replacing System Configuration Card
PSU Serial B Serial A
LEDs
FIGURE 11-1
shows the locations of the Netra T4 system back panel connectors.
Wrist Strap Attachment
USB
SCSI Ethernet
Back Panel Connectors (AC100 Shown)
Alarms Port
FC-AL PCI Slot LOMlite2
(short) Serial
LOMlite2 LEDs
Appliance PCI Slot
Inlet (long)
11-1
