B.2

Electrical Specification

B.2.1

Netra T4 AC100 System

B.2.1.1 Operating Voltage and Frequency
TABLE B-1
Voltage
Frequency
B.2.1.2 Current
Inrush
The maximum inrush current is 25 A
been removed for 60 s or longer. Circuit breakers must not be tripped by an inrush
current of 25 A lasting 200 ms.
Operating
The maximum normal input line current is less than 7.2 A
standard test conditions.
Power Off Mode
The maximum input power of the system in power off or remote off state is less than
30 VA.
B-2 Netra T4 AC100/DC100 Service and System Reference Manual • August 2001
AC Power Supply Input Requirements
Minimum
90 V
rms
47 Hz
Maximum
264 V
rms
63 Hz
upon start up or restart after power has
peak
at 100 VAC under
rms
