TABLE 10-8
Designation
J3203
J3302
J3303
J3501
J3601
J3602
J3603
J3604
J3605
J3608
J4301
J4401
J4501
J5002
J5301
10.5
Jumper Descriptions
Jumper configurations can be changed from the default settings by setting jumper
switches on the motherboard.
A jumper switch is closed (sometimes referred to as shorted) with the plastic cap
inserted over two pins of the jumper. A jumper is open with the plastic cap inserted
over one or no pin(s) of the jumper.
10-40
Netra T4 AC100/DC100 Service and System Reference Manual • August 2001
Motherboard Component Functions (Continued)
Function
Not used
Not used
Not used
Server RSC connector
Power supply connector
Combined cable connector
Power supply connector
Smart card reader connector
Not used
Peripheral power cable connector
Not used
Not used
Not used
SCSI connector
Ethernet rear panel connector
