Sun Microsystems Netra T4 AC100 Service And System Reference Manual page 201

68-Pin SCSI Connector Pinout (Continued)
TABLE 11-3
Pin Signal Name
13 GND
14 GND
15 GND
16 GND
17 TERMPWR
18 TERMPWR
19 Not connected
20 GND
41 –DB<1>
42 –DB<2>
43 –DB<3>
44 –DB<4>
45 –DB<5>
46 –DB<6>
47 –DB<7>
48 –PAR<0>
49 GND
50 TERM.DIS
51 TERMPWR
52 TERMPWR
53 Reserved
54 GND
Note – All signals shown in
Pin
33
34
35
36
37
38
39
40
55
56
57
58
59
60
61
62
63
64
65
66
67
68
are active low.
TABLE 11-3
Chapter 11 External I/O Connectors
Signal Name
GND
GND
–DB<12>
–DB<13>
–DB<14>
–DB<15>
–PAR<1>
–DB<0>
–ATN
GND
–BSY
–ACK
–RST
–MSG
–SEL
–CD
–REQ
–IO
–DB<8>
–DB<9>
–DB<10>
–DB<11>
11-5
