TABLE D-3
Pin
5
6
9
10
13
14
17
18
D.4 Power Connectors
The motherboard has seven power connectors. The following table lists these power
connectors, the connector use, and the supporting figure and table. xx identifies the
motherboard connector location.
TABLE D-4
Connector
J3603
J3601
J3303
J3602
J3608
Internal FC-AL Connector, J2901 (Continued)
Signal Name
T_DR2_PORT2IN_P
T_DR2_PORT2IN_N
DR2_PORT2OUT_P
DR2_PORT2OUT_N
T_DR1_PORT1IN_P
T_DR1_PORT1IN_N
DR1_PORT1OUT_P
DR1_PORT1OUT_N
Power Connectors
Use
Power from power
supply
Power from power
supply
Power to CPU fan
Power to combined
cable assembly
Power to peripheral
power cable assembly
Supporting Figure
FIGURE D-3
FIGURE D-4
Appendix D Motherboard Connectors
Supporting Table
TABLE D-5
TABLE D-6
D-5
