# Configure Bri0/0/0 PPP authentication information and the Dialer bundle to which the
interface belongs.
[3Com-Dialer1] interface bri 0/0/0
[3Com-Bri0/0/0] undo dialer enable-circular
[3Com-Bri0/0/0] dialer bundle-member 1
[3Com-Bri0/0/0] dialer bundle-member 2
[3Com-Bri0/0/0] link-protocol ppp
[3Com-Bri0/0/0] ppp authentication-mode pap
[3Com-Bri0/0/0] ppp pap local-user usera password simple usera
2) Configure RouterB:
# Configure dial-up ACL and local usera.
[3Com] dialer-rule 2 ip permit
[3Com] local-user usera
[3Com-luser-usera] password simple usera
[3Com-luser-usera] service-type ppp
[3Com-luser-usera] quit
# Configure Dialer0 interface address and enable RS-DCC.
[3Com] interface dialer 0
[3Com-Dialer0] ip address 100.1.1.2 255.255.255.0
[3Com-Dialer0] undo dialer enable-circular
[3Com-Dialer0] dialer user usera
[3Com-Dialer0] dialer bundle 1
[3Com-Dialer0] dialer number 8810148
# Configure the users that are allowed to dial-up Dialer0 interface, PPP authentication
information and the DCC to the remote end.
[3Com-Dialer0] dialer-group 2
[3Com-Dialer0] ppp authentication-mode pap
[3Com-Dialer0] ppp pap local-user userb password simple userb
# Configure Bri0/0/0 PPP authentication information and the Dialer bundle to which the
interface belongs.
[3Com-Dialer0] interface bri 0/0/0
[3Com-Bri0/0/0] undo dialer enable-circular
[3Com-Bri0/0/0] dialer bundle-member 1
[3Com-Bri0/0/0] link-protocol ppp
[3Com-Bri0/0/0] ppp authentication-mode pap
[3Com-Bri0/0/0] ppp pap local-user usera password simple usera
3) Configure RouterC
# Configure dial-up ACL and local usera.
[3Com] dialer-rule 1 ip permit
[3Com] local-user usera
