3Com Router 3000 Ethernet Family
Configuration Guide
Table 1-11 Configure a dialer interface and dialer number
Create a dialer interface, and enter the dialer
interface view
Delete the existing configuration of the dialer
interface
Configure a dialer number for calling a remote
end
Delete the dialer number for calling a remote
end
By default, no dialer interface is created.
III. Creating dialer bundle and assigning physical interfaces to it
To implement the RS-DCC, the system selects a physical interface based on the dialing
priority from a dialer bundle. The command dialer bundle is used for creating the dialer
bundle for a Dialer interface and the dialer user command is used to enable the
RS-DCC function simultaneously, which is mentioned above.
Perform the following configuration steps in physical interface view.
Table 1-12 Creating a dialer bundle and assigning the physical interfaces to it
Add a physical interface to the specified
dialer bundle
Delete the physical interface from the
dialer bundle
By default, no dialer bundle is created, and the physical interfaces do not belong to any
dialer bundle. If a physical interface is assigned to a dialer bundle, a default priority of 1
is assigned.
IV. Configuring dialing authentication for RS-DCC
To implement the RS-DCC, it is required for the called party to identify the calling
parties through authentication because of the complicated map relations between the
physical interfaces and the dialer interfaces. Therefore, PAP or CHAP authentication
must be configured.
Use dialer user in dialer interface view, local-user in system view, password in local
user view, and other configuration tasks in dial interface (physical or dialer interface)
view.
Operation
Operation
3Com Corporation
1-18
Chapter 1 DCC Configuration
Command
interface dialer number
undo interface dialer number
dialer number dial-number
undo dialer number
Command
dialer bundle-member
[ priority priority ]
undo dialer bundle-member number
number
