Figure 3-12. Utility Demodulator; Figure 3-23. Utility Demodulator (Type 1 Operation) - Comtech EF Data SDM-100A Installation And Operation Manual

Operation
SDM-100 "TYPE"
VER: 14.7.4
ASSIGN RECEIVE
FILTERS
x = FILTER A, B, C, D, or V
RX-A QPSK 1/2 [64.000 kbit/s]
RX-B QPSK 1/2 [96.000 kbit/s]
RX-C QPSK 1/2 [128.000 kbit/s]
RX-D QPSK 1/2 [32.000 kbit/s]
RX-V QPSK 1/2 [19.200 kbit/s]
code_rate = QPSK or BPSK
m/n = 1/2, 3/4, 7/8
3–70
FUNCTION SELECT
UTILITY
DEMODULATOR
TYPE
CSC CLOSED
FDC CLOSED
EFD CLOSED

Figure 3-23. Utility Demodulator (Type 1 Operation)

UTILITY
DEMODULATOR
BER THRESHOLD
1.0 E-3 to 1.0 E-8
Key:
ACCESS TO
CONDITIONAL OR
SUBMENU
OPTION-DEPENDENT
SDM-100A Satellite Modem
NONE
Parameter Information
Rev. 0
