AMD Athlon Processor x86 Optimization Manual page 183

22007E/0—November 1999
Table 11. Performance-Monitoring Counters (Continued)
Event Source
Number Unit
D5h FR
D6h FR
D7h FR
D8h FR
D9h FR
DAh FR
DCh FR
DDh FR
DEh FR
DFh FR
PerfCtr[3:0] MSRs (MSR Addresses C001_0004h–C001_0007h)
Performance Counter Usage
Notes / Unit Mask (bits 15–8)
The performance-counter MSRs contain the event or duration
counts for the selected events being counted. The RDPMC
instruction can be used by programs or procedures running at
any privilege level and in virtual-8086 mode to read these
counters. The PCE flag in control register CR4 (bit 8) allows the
use of this instruction to be restricted to only programs and
procedures running at privilege level 0.
The RDPMC instruction is not serializing or ordered with other
instructions. Therefore, it does not necessarily wait until all
previous instructions have been executed before reading the
counter. Similarly, subsequent instructions can begin execution
before the RDPMC instruction operation is performed.
Only the operating system, executing at privilege level 0, can
directly manipulate the performance counters, using the
RDMSR and WRMSR instructions. A secure operating system
would clear the PCE flag during system initialization, which
disables direct user access to the performance-monitoring
counters but provides a user-accessible programming interface
that emulates the RDPMC instruction.
The WRMSR instruction cannot arbitrarily write to the
performance-monitoring counter MSRs (PerfCtr[3:0]). Instead,
the value should be treated as 64-bit sign extended, which
AMD Athlon™ Processor x86 Code Optimization
Event Description
ICU full
Reservation stations full
FPU full
LS full
All quiet stall
Far transfer or resync branch pending
Breakpoint matches for DR0
Breakpoint matches for DR1
Breakpoint matches for DR2
Breakpoint matches for DR3
167
