Fast Conversion of Signed Words to Floating-Point

Use MMX™ PXOR to Negate 3DNow!™ Data
Fast Conversion of Signed Words to Floating-Point
In many applications there is a need to quickly convert data
consisting of packed 16-bit signed integers into floating-point
numbers. The following two examples show how this can be
accomplished efficiently on AMD processors.
The first example shows how to do the conversion on a processor
that supports AMD 's 3 DN ow! ex te n si on s, such as t h e
AMD Athlon processor. It demonstrates the increased
efficiency from using the PI2FW instruction. Use of this
instruction should only be for AMD Athlon processor specific
code. See the AMD Extensions to the 3DNow!™ and MMX™
Instruction Set Manual, order #22466 for more information on
this instruction.
The second example demonstrates how to accomplish the same
task in blended code that achieves good performance on the
AMD Athlon processor as well as on the AMD-K6 family
processors that support 3DNow! technology.
Example 1 (AMD Athlon specific code using 3DNow! DSP extension):
MOVD MM0, [packed_sword]
PUNPCKLWD MM0, MM0
PI2FW MM0, MM0
MOVQ [packed_float], MM0
Example 2 (AMD-K6 Family and AMD Athlon processor blended code):
MOVD MM1, [packed_sword]
PXOR MM0, MM0
PUNPCKLWD MM0, MM1
PSRAD MM0, 16
PI2FD MM0, MM0
MOVQ [packed_float], MM0
For both the AMD Athlon and AMD-K6 processors, it is
recommended that code use the MMX PXOR instruction to
change the sign bit of 3DNow! operations instead of the 3DNow!
PFMUL instruction. On the AMD Athlon processor, using
PXOR allows for more parallelism, as it can execute in either
the FADD or FMUL pipes. PXOR has an execution latency of
two, but because it is a MMX instruction, there is an initial one
AMD Athlon™ Processor x86 Code Optimization
;0 0 | b a
;b b | a a
;xb=float(b) | xa=float(a)
;store xb | xa
;0 0 | b a
;0 0 | 0 0
;b 0 | a 0
;sign extend: b | a
;xb=float(b) | xa=float(a)
;store xb | xa
