AMD Athlon™ Processor x86 Code Optimization
Efficient 3D-Clipping Code Computation Using 3DNow!™
Instructions
.DATA
RIGHT EQU 01h
LEFT EQU 02h
ABOVE EQU 04h
BELOW EQU 08h
BEHIND EQU 10h
BEFORE EQU 20h
ALIGN 8
ABOVE_RIGHT DD
DD
BELOW_LEFT DD
DD
BEHIND_BEFORE DD
DD
.CODE
;; Generalized computation of 3D clip code (out code)
;;
;; Register usage: IN
;;
;;
;;
122
Clipping is one of the major activities occurring in a 3D
graphics pipeline. In many instances, this activity is split into
two parts which do not necessarily have to occur consecutively:
Computation of the clip code for each vertex, where each
bit of the clip code indicates whether the vertex is outside
the frustum with regard to a specific clip plane.
Examination of the clip code for a vertex and clipping if the
clip code is non-zero.
The following example shows how to use 3DNow! instructions to
efficiently implement a clip code computation for a frustum
that is defined by:
-w <= x <= w
-w <= y <= w
-w <= z <= w
RIGHT
ABOVE
LEFT
BELOW
BEFORE
BEHIND
MM5 y | x
MM6 w | z
OUT MM2 clip code (out code)
Efficient 3D-Clipping Code Computation Using
