▼ Install the Server (19-Inch, 4-Post Sliding Rail
Rackmount Kit)
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 863.6 mm (34 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See
2. Use four of the supplied M5 x 4.5 mm flathead Phillips screws to secure each of
the hardmount brackets to the sides of the server.
These hardmount brackets and screws are shipped with the standard server ship
kit, not as part of the sliding rail 19-inch, 4-post rackmount kit.
3. Press in the button on each slide assembly and pull the glide completely out of
the slide.
32 Netra SPARC T4-1 Server Installation Guide • January 2013
"Rack Cautions" on page 24.
