▼ Install the Server (19-Inch, 4-Post Hardmount
Rackmount Kit)
Note – The front-to-back rail spacing must be at least 460 mm (18.11 in.) and not
more than 715 mm (28.15 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See
2. Use four of the supplied M5 x 4.5-mm flathead Phillips screws to secure each of
the hardmount brackets to the sides of the server.
3. Measure the depth of the rack.
4. Install the rear mount support brackets at the rear of the server, extending the
rear mount support brackets to the measured depth of the rack.
Use two to three of the supplied M4 x 0.5 x 5 mm panhead Phillips screws for each
bracket, depending on the rack depth.
28 Netra SPARC T4-1 Server Installation Guide • January 2013
"Rack Cautions" on page 24.
