4.12
For the monitoring of the system bus and the display of the internal states, two con-
trol parameters are provided. There is a report of the system bus state and a report of
the CAN state via two actual value parameters.
The parameter
erational, Stopped state. A PDO transfer is only possible in the Operational state. The
state is controlled by the system bus master (PLC / PC / frequency inverter) via NMT
telegrams.
The parameter
layer. If there are transmission errors, the state changes from OKAY to WARNING
until the cancellation of the communication with BUS-OFF. After BUS-OFF, the CAN
controller is automatically re-initialized and the system bus started again.
Note:
After Bus-OFF, the system bus in the frequency inverter is completely reinitialized.
There is a new boot-up message from the node and an emergency telegram with the
Bus-OFF message is transmitted. The change of state of the node to Operational is
done by the Start-Remote-Node telegram cyclically sent by the system bus master.
978 Node-State
979 CAN-State
06/05
06/05

Control parameters

Node-State
CAN-State
If the BUS-OFF state occurs, the frequency inverter enters fault state with
"F2210 BUS-OFF".
No.
Description
978 provides information about the Pre-Operational, Op-
979 provides information about the state of the physical
Actual values of the system bus
1 - Pre-Operational
2 - Operational
3 - Stopped
1 - OKAY
2 - WARNING
3 - BUS-OFF
Display
41
41
