144
AXCESS Programming
Shorthand Send_Commands (Cont.)
Command
"'@CFF',<variable text
address>,<color_
number>"
"'@CFN',<variable text
address>,<color_
number>"
"'@CPG',<color_number>,
'<page name>'"
"'@CPP',<color_number>,
'<pop-up page name>'"
Description
Set the OFF feedback fill color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'@CFF',1,72"
Sets the OFF feedback fill color to White for variable text
button 1.
Set the ON feedback fill color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'@CFN',1,30"
Sets the ON feedback fill color to Aqua for variable text button
1.
Set the page with specified page name background color to
the specified color.
<color_number> = see Figure 202
<page name> = 1 - 50 ASCII characters
Example:
SEND_COMMAND TP,"'@CPG',87,'Main Page'"
Sets the page title to Main Page, and the color to Black.
Set the page with specified page name background color to
the specified color.
<color_number> = see Figure 202
<pop-up page name> = 1 - 50 ASCII characters
Example:
SEND_COMMAND TP,"'@CPP',54,'Audio Page'"
Sets the popup page title to Audio Page, and the color to
Purple.
ViewPoint Wireless Touch Panels
