Note
The GROUP ID number can
be set from the Wireless Set-
tings page in the Protected
Setup page. Refer to the
Wireless settings subsections
for detailed information.
Note
The Network Eff. XXX% and
Device Eff. XXX% information
buttons are the best indicators
of communication.
ViewPoint Wireless Touch Panels
•
Wave-Pak Not Locked/Locked
is connected to the touch panel. Not locked indicates the touch panel is not
communicating with the AXR-WAVES. Locked indicates the touch panel is
locked on (communicating) to the AXR-WAVES connected to the Central
Controller.
•
Battery Voltage XX.X
rechargeable battery in the WAV-PK.
• Shows the strength of the AXR-WAVES signal received by
RSSI XXX%
the touch panel. The signal strength fluctuates between 0% and 100% as
shown by a horizontal gauge moving from left to right.
• Shows the GROUP ID number on the touch panel used to
GROUP ID
communicate with the wireless AXR-WAVES with the same group ID
number. The group ID range is 0 – 15. The group ID setting overrides the
DIP switch setting on the WAV-PK.
•
Module Version vX.XX
WAV-PK.
•
Fully Charged/Not Charging/Charging
the battery in the WAV-PK is fully charged. Not Charging appears when the
lead-acid battery is not charging. Charging appears when the lead-acid
battery is charging. The shaded area is a horizontal gauge moving from left
to right as the battery voltage level increases.
•
Network Eff. XXX%
RF transmissions between the touch panel and AXR-WAVES. The efficiency
percentage (0–100%) is determined by the number of retries required to
complete a panel operation.
•
Shows the device range that your server can recognize.
Device Range
Devices outside that range will not be recognized.
•
Server Devices XXX
communicating with the touch panel.
•
Shows the firmware version installed in the AXR-
Server Version
WAVES.
•
Supply Voltage vX.XX
supply (optional) connected to the WAV-PK.
•
Device Eff. XXX%
received by the touch panel. The shaded area in the horizontal gauge moves
Appears when an optional WAV-PKM
Shows the voltage level of the lead-acid
Shows the firmware version installed in the
Fully Charged appears when
Shows the communication efficiency of bidirectional
Shows the group address for the AXR-WAVES
Shows the voltage level of the external power
Shows the strength of the AXR-WAVES signal
