ViewPoint Wireless Touch Panels
Color Send_Commands (Cont.)
Command
"'CBOFF<variable text
address>-<color
_number>'"
"'CBON<variable text
address>-<color
_number>'"
"'CFOFF<variable text
address>-<color
_number>'"
Description
BORDER COLOR ON = Red brightest
BORDER COLOR OFF = Red brightest
TEXT COLOR ON = White brightest
TEXT COLOR OFF = White two shades from brightest
Set the OFF feedback border color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CBOFF1-0'"
Sets the OFF feedback border color to Red for the variable
text button 1.
Set the ON feedback border color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CBON1-48'"
Sets the ON feedback border color to Blue for variable text
button 1.
Set the OFF feedback fill color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CFOFF1-72'"
Sets the OFF feedback fill color to White for variable text
button 1.
AXCESS Programming 149
