Figure 120
Function show button and
slider example
Figure 121
ViewPoint 2-way Wireless
Settings
Note
The GROUP ID can be
altered. Once changed, the
value is reflected in the
GROUP ID button located in
the WAV-PKM page. Refer to
the Wireless status (optional
WAV-PKM) subsection for
detailed information.
80 Touch Panel Program Reference
Base
device
3, 132
Button
LIGHT
PANEL
Variable text
device number
Text channel

Wireless Settings for VPW-CP and VPW-GS

The WIRELESS STATUS button appears on the Setup page. The ViewPoint provides
two-way RF control and provides one-way IR signaling. The ViewPoint contains a
Nickel Metal Hydride rechargeable battery that supplies independent power to the
touch panel. Press the WIRELESS SETTINGS button to open the page shown in
Figure 121.
Channel code
number
2, 1
Slider
2, 255
1,255
Level channel
Level device
number
ViewPoint Wireless Touch Panels
