Note
Page names are case-
sensitive.
150 AXCESS Programming
Color Send_Commands (Cont.)
Command
"'CFON<variable text
address>-<color
_number>'"
"'CPAGE<color_number>-
<page name>'"
"'CTOFF<variable text
address>-<color
_number>'"
"'CTON<variable text
address>-<color
_number>'"
Description
Set the ON feedback fill color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CFON1-48'"
Sets the ON feedback fill color to Blue for variable text
button 1.
Set the background page color to the specified color.
<color_number> = see Figure 202
<page name> = 1 - 50 ASCII characters
Example:
SEND_COMMAND TP,"'CPAGE48-MAIN PAGE'"
Sets the background color on the MAIN PAGE to Blue.
Set the OFF feedback text color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CTOFF1-48'"
Sets the OFF feedback text color to Blue for variable text
button 1.
Set the ON feedback text color to the specified color.
<variable text address> = 1 - 255
<color_number> = see Figure 202
Example:
SEND_COMMAND TP,"'CTON1-72'"
Sets the ON feedback text color to White for variable text
button 1.
ViewPoint Wireless Touch Panels
