Figure 93

Protected Setup page

flowchart
Note
When the Edit bar is enabled,
you do not have to enter the
password when opening the
Protected Setup page.
70 Touch Panel Program Reference

Device range

Indicates the assignable device number range (for RF operation) available for the
VPW-CP or VPW-GS.

Server devices

Identifies the device numbers of the devices communicating with the AXR-WAVES
WaveServer.
Protected Setup Page
The Protected Setup page allows you to set passwords, mouse controls, and
communications parameters. The flowchart in Figure 93 shows how to access the
Protected Setup page, which is password-protected. When you press the
PROTECTED SETUP button on the Setup page, a number keypad appears.
MAIN SETUP
PAGE BUTTON
Type 1988, which is the system default password, and press ENTER to open the
Protected Setup page. (You can change the password, as explained in the Setup
Password subsection.) If you enter a wrong number, press CLEAR and re-enter the
number. The Protected Setup page (Figure 94) appears when you enter the correct
password.
PROTECTED SETUP
BUTTON
ViewPoint Wireless Touch Panels
TYPE
1988
