Figure 208
Shorthand variable text
commands
Note
Shorthand commands were
created by AMX designers to
streamline receiving,
processing, and transmitting
Central Controller data. The
short-hand commands
operate Control Equipment
just like the standard
Send_Commands still used in
a wide variety of AMX
products, but they are simply
smaller byte-for-byte, and
thus processed more
efficiently.
154
AXCESS Programming
Shorthand variable text commands
Command
"'@BMF',<variable text
address>,'<attribute
data>'"
Description
Set multiple attributes to a button, slider, or gauge. This
command allows you to program up to 12 attributes on one
command line.
<variable text address> = 1 - 255
<optional data> = See below
Optional data:
'%B',<border styles> = See Figure 204
'%F',<font styles> = See Figure 203
'%T',<button text > = ASCII characters (empty is clear)
'%P',<bitmap> = Bitmap filename (empty is clear)
'%I',<icon> = 1 - 255 (icon numbers are assigned in
TPDesign3 project file)
'%J',<text alignment> = 1 - 9 as shown the following alignment
chart
1
2
3
4
5
6
7
8
9
'%C1',<on-state fill color> = See Figure 202 for color numbers
'%C2',<off-state fill color> = See Figure 202 for color numbers
'%C3',<on-state border color> = See Figure 202 for color
numbers
'%C4',<off-state border color> = See Figure 202 for color
numbers
'%C5',<on-state text color> = See Figure 202 for color
numbers
'%C6',<off-state text color> = See Figure 202 for color
numbers
Example:
SEND_COMMAND TP,"'@BMF',255,'%T POWER |ON
'%B',4',%C1',72'"
Sets the text on button 255 to POWER ON (appears on two
lines), adds a triple-line border, and sets the On-state color to
White.
ViewPoint Wireless Touch Panels
