Operation/Reference Guide
MVP-5100/5150
Modero® Viewpoint
Widescreen Touch Panels
M i o M o d e r o T o u c h P a n e l s
L a s t U p d a t e d : 1 2 / 2 / 2 0 0 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modero MVP-5150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AMX Modero MVP-5150

Summary of Contents for AMX Modero MVP-5150

  • Page 1 Operation/Reference Guide MVP-5100/5150 Modero® Viewpoint Widescreen Touch Panels M i o M o d e r o T o u c h P a n e l s L a s t U p d a t e d : 1 2 / 2 / 2 0 0 8...
  • Page 2 Products repaired under this policy will carry a ninety (90) day warranty on material and labor. • AMX will notify the AMX Authorized Partner with the cost of repair, if cost is greater than the Standard Repair Fee, within five (5) days of receipt.

  • Page 3: Fcc Information

    FCC Information This device complies with Part 15 of the FCC Rules and Industry Canada RSS 210, subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of...
  • Page 4 LICENSE GRANT. AMX grants to Licensee the non-exclusive right to use the AMX Software in the manner described in this License. The AMX Software is licensed, not sold. This license does not grant Licensee the right to create derivative works of the AMX Software.

  • Page 5: Table Of Contents

    Table of Contents Introduction ...1 MVP-5150 5.2" Modero ViewPoint WiFi Touch Panel ... 2 MVP-5100 5.2" Modero ViewPoint IR Touch Panel ... 4 Memory ... 5 Table Charging Station Connector Locations... 5 Basic Operation ... 6 Audio/Video Capabilities ... 6 Power Management...
  • Page 6 Table of Contents Automatically setting SSID ... 29 Manually setting SSID... 29 Configuring multiple wireless touch panels to communicate to a target WAP... 32 Step 3: Choose a Master Connection Mode ... 33 Panel downloads and firmware updates ... 34 Touch panel setup ...
  • Page 7 Uploading IR Codes to the MVP-5100 ... 93 Adding an existing IR file to NetLinx Studio ... 95 Adding an AMX IR Database file to NetLinx Studio ... 96 Adding a personal IR Database file to NetLinx Studio ... 98 Programming ...99...
  • Page 8 Terminology... 157 EAP Authentication... 160 EAP characteristics ... 160 EAP communication overview ... 161 AMX Certificate Upload Utility ... 162 How to Upload a Certificate File... 162 Appendix C: Troubleshooting ...164 Panel Doesn’t Respond To Touches ... 164 Battery Will Not Hold Or Take A Charge ... 164 Device Isn’t Appearing In The Online Tree Tab ...

  • Page 9: Introduction

    Introduction The MVP-5100 Modero® Viewpoint® IR Touch Panel (FG5966-08) and the MVP-5150 Modero® Viewpoint® WiFi Touch Panel (FG5966-07) are wireless ergonomic devices, with all control established through a NetLinx Master or through an IR receiver. Both utilize a 5.2" Color Active LCD to display a 800 x 480 pixel image with 262,144 colors.

  • Page 10: Mvp-5150 5.2" Modero Viewpoint Wifi Touch Panel

    • PROCESSOR SHUTDOWN: Power to all peripherals and components is turned off. The system remains in this mode until it is rebooted. The panel is re-activated by pressing the touchscreen and holding until the AMX splash screen appears. • FCC Part 15 Class B •...
  • Page 11 Transmit IR over 20 feet (6.10 m) from the panel. • IR emitters on G4 panels share the device address number of the panel. • Transmits AMX fixed frequencies at 38KHz and 455KHz and 8 user- programmable frequencies from 20KHz to 1.5MHz •...

  • Page 12: Mvp-5100 5.2" Modero Viewpoint Ir Touch Panel

    Introduction MVP-5100 5.2" Modero ViewPoint IR Touch Panel The MVP-5100 differs from the MVP-5150 in that it does not have a built-in wireless card or the capacity to install one, and only communicates with other devices via IR. Otherwise, the two devices are identical.

  • Page 13: Table Charging Station Connector Locations

    With the unit facing you, the mini-USB port (for programming and downloading firmware using the AMX-provided adaptor cable) and the DC power port are located on the lower left side of the device (FIG. 3). The connector for the Table Charging Station (please refer to the Table Charging Station section on page 7) is located on the bottom of the device.

  • Page 14: Basic Operation

    Introduction Transferring firmware KIT files over a direct USB connection should only be done when the panel is connected to a power supply. If battery power fails during a firmware upgrade, the panel flash file system may become corrupted. Basic Operation The MVP-5100 and MVP-5150 are operated using their integral touchscreens.

  • Page 15: Table Charging Station

    Rear Connector: Operating/ Storage Environments: Included Accessories Other AMX Equipment: MVP-5100/5150 Modero Viewpoint Touch Panels • 8.0” x 4.75” x 3.5” (20.32cm x 12.07cm x 8.89cm) • .65 lbs (.29 kg) • 5-pin charging connector on bottom of charging cradle.

  • Page 16: Powering The Mvp-Tcs-52

    Powering the MVP-TCS-52 The MVP-TCS-52 uses a PS3.0 power supply (included with the touch panel or available separately from www.amx.com) to provide direct power for the MVP panel both for standard functions and for charging its internal battery. 1. Connect the terminal end of the PS3.0 power supply to the PWR connector on the bottom of the MVP-TCS-52.

  • Page 17: Wall Charging Station

    • 8.375" x 6.09" x 2.19" (21.27 cm x 15.46 cm x 5.56 cm) Note: Always use the cutout/installation dimensions for the MVP-WCS-52 when installing this unit into various surfaces. This SP engineering drawing is available online at www.amx.com. • 3 A @ 12 VDC (Class II listed power supplemented) • Total: 1.7A •...

  • Page 18: Unlocking The Touch Panel

    Environments: Included Accessories Other AMX Equipment: The touch panel remains locked in the MVP-WCS-52 until unlocked by the user. This may be done by entering an appropriate password (please refer to the Password Settings Page section on page 83 for more information), or by pressing the Security Release button on the front of the device in emergencies.

  • Page 19: Recharging

    Recharging To recharge the touch panel: 1. Slide the device into the Wall Charging Station cradle bottom-first and make sure the device is fully seated in the Charging Station. 2. Press the top of the touch panel back until it clicks. The touch panel is now locked into the Charging Station, and the station will automatically charge the device’s battery.

  • Page 20: Installing The Mvp-Wcs-52

    Accessories Installing the MVP-WCS-52 Since the Wall Charging Station is intended to be affixed to a wall or other permanent structure, care must be taken to ensure its proper installation to prevent potential damage to any touch panel placed within. Other than wall installation tools, the only tool required for this installation is a #1 Phillips screwdriver.
  • Page 21 To assist with wiring, and to avoid mechanical stresses on the wire and the mechanism of the Wall-Mounted Charging Station, the top right knockout is preferred for use. 3. Run the power cable through the knockout into the box. Pull out about six inches (15.25cm) of cable into the box to facilitate installation of the MVP-WCS-52.
  • Page 22 Accessories Strip 0.25 inch (6.35 mm) of wire insulation off all wires. Insert each wire into the appropriate opening on the connector. Turn the screws clockwise to secure the wires in the connector. Do not over-torque the screws; doing so can bend the seating pins and damage the connector. 7.
  • Page 23 FIG. 10 Installation of MVP-WCS-52 For ease of installation, put each screw on a neodymium magnet in the device’s interior compartment to keep them on hand until they are needed. 11. After fully seating the screws, wipe down the area around the screw holes with the alcohol prep pad from the Installation Kit.

  • Page 24: Installing The Optional Metal Rough-In Box

    Accessories Installing the Optional Metal Rough-In Box The optional Metal Rough-In Box (FG037-11) is 10 inches (25.40cm) wide at its widest dimension (wider than the bezel of the Wall Charging Station), and is only intended for pre construction installations (FIG. 11). The Metal Rough-In Box is used in conjunction with the Wall Charging Station’s plastic back box.

  • Page 25: Other Mvp-Wcs-52 Installations

    Other MVP-WCS-52 installations The Wall-Mounted Charging Station is designed to be installed in various different locations, such as into the face of a wooden podium or the top of a table. Depending upon the ability to wire it to a power source, Wall-Mounted Charging Stations may be installed on vertical or horizontal surfaces composed of such materials as wood, brick, and glass.
  • Page 26 Accessories MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 27: Configuring Communication

    WiFi Card. Before commencing, verify you are using the latest NetLinx Master and Modero panel-specific firmware. Verify you are using the latest versions of AMX’s NetLinx Studio and TPDesign4 programs. Attempting uploads of drivers and firmware with older versions of NetLinx Studio and TPDesign4 will fail.

  • Page 28: Ir Communication

    Configuring Communication IR Communication Both the MVP-5100 and MVP-5150 may be used as infrared remote devices for other AMX controllers or third-party devices. The devices can transmit IR over 20 feet (6.10 m) from the panel at frequencies of 38KHz and 455KHz, as well as up to eight user-programmed frequencies between 20KHz and 1.5MHz.

  • Page 29: Modero Setup And System Settings

    Modero Setup and System Settings All AMX Modero panels, including the MVP-5100 and MVP-5150, feature on-board Setup pages. Use the options in the Setup pages to access panel information and make various configuration changes. Accessing the Setup and Protected Setup Pages 1.

  • Page 30: Setting The Panel's Device Number

    Configuring Communication The default password for the Protected Setup page is 1988, but this may be changed at any time. For more information on the Setup and Protected Setup pages, refer to the Setup Pages section on page 45 and the Protected Setup Pages section on page 55. Setting the Panel’s Device Number In the Protected Setup page: 1.

  • Page 31: Wireless Settings - Wireless Access Overview (Mvp-5150 Only)

    Type. The Wireless Access Point communication parameters must match those of the pre-installed wireless CF card inside the device. MVP touch panels connect to a wireless network through their use of the pre-installed AMX 802.11g wireless interface card. This allows users to communicate with a Wireless Access Point (WAP). The WAP communication parameters must match those of the pre-installed wireless interface card installed within the panel.

  • Page 32: Wireless Communication Using A Dhcp Address

    Configuring Communication Wireless communication using a DHCP Address In the Protected Setup page: 1. Select Wireless Settings. Wireless communication is set within the IP Settings section of this page (FIG. 15). FIG. 15 Wireless Settings page (IP Settings section) 2. Toggle the DHCP/Static field from the IP Settings section until the choice cycles to DHCP. This action causes all fields in the IP Settings section, other than Host Name, to be greyed-out.

  • Page 33: Wireless Communication Using A Static Ip Address

    Wireless communication using a Static IP Address 1. From the Protected Setup page, press the Wireless Settings button to open the Wireless Settings page. Wireless communication is set within the IP Settings section of this page (FIG. 15). Check with your System Administrator for a pre-reserved Static IP Address to be assigned to the panel.

  • Page 34: Using The Site Survey Tool

    Configuring Communication Using the Site Survey tool This tool allows a user to "sniff out" all transmitting Wireless Access Points within the detection range of the internal wireless card (FIG. 16). Once the Site Survey button is pressed, the device displays the Site Survey page, which contains the following categories: Network Name (SSID) - Wireless Access Point names Channel (RF) - Channel currently being used by the WAP (Wireless Access Point)

  • Page 35: Step 2: Configure The Card's Wireless Security Settings

    If the panel detects more than 10 WAPs, the Up/Down arrows at the far right side of the page become active (blue) and allow the user to scroll through the list of entries. 4. Select a desired Access Point by touching the corresponding row. The up arrow and down arrow will be grayed out if ten or fewer access points are detected.
  • Page 36 The card should be given the SSID used by the target WAP. If this field is left blank, the unit will attempt to connect to the first available WAP. By default, all WAP250Gs use AMX as their assigned SSID value.

  • Page 37: Automatically Setting Ssid

    6. Click Done when complete. 7. From the Open (Clear Text) Settings page (FIG. 19), press the Save button to incorporate the new information into the device and begin the communication process. 8. Verify the proper configuration in the fields in the IP Settings section. Refer to Step 1: Configure the Device’s Wireless IP Settings (MVP-5150 Only) section on page 23 for detailed information.
  • Page 38 SSID. The same case must be maintained when entering this information. ABC is not the same as Abc. The alpha-numeric string is AMX by default, but can later be changed to any 32-character entry. This string must be duplicated within the Network Name (SSID) field on the WAP. As an example, if the SSID is MINISTRY, this word and the case within must match both the Network Name (SSID) field on the touch panel’s Network Name SSID field and on the WAP’s...
  • Page 39 6. Toggle the Default Key field to choose a WEP Key value (from 1- 4) that matches what will be used on the target. This value MUST MATCH on both devices. These WEP Key identifier values must match for both devices. 7.

  • Page 40: Configuring Multiple Wireless Touch Panels To Communicate To A Target Wap

    Configuring Communication 12. Verify that the fields within the IP Settings section have been properly configured. Refer to Step 1: Configure the Device’s Wireless IP Settings (MVP-5150 Only) section on page 23 for detailed information. 13. Press the Back button to navigate to the Protected Setup page and press the on-screen Reboot button to save any changes and restart the panel.

  • Page 41: Step 3: Choose A Master Connection Mode

    Step 3: Choose a Master Connection Mode Since the MVP-5150 may connect with a Master via USB or Ethernet, this requires a decision on the type of connection to be made between it and the Master. The MVP-5100 may only use USB for connection.

  • Page 42: Panel Downloads And Firmware Updates

    1. Turn on the device and wait for it to finish booting up. 2. Make sure that you have downloaded the latest versions of NetLinx Studio and TPDesign4, available from www.amx.com. 3. Insert the mini-USB end of the USB Programming Cable into the mini-USB port on the device.
  • Page 43 6. In the new window: - Select Use the following IP Address. Under IP address, provide an IP address. Ensure that it is in the same subnet as the IP address given to the usb0 interface on the MVP-5100, but make sure that it has a different node number.
  • Page 44 1. From the Windows XP desktop, click on Start > Control Panel > Network Connections > Local Area Connection. This opens a window listing the currently active network connections. 2. Select the connection to the device name of AMX USB Device Link. MVP-5100/5150 Modero Viewpoint Touch Panels...
  • Page 45 3. Right click on the selected device and select Properties to open the Local Area Connection Properties window (FIG. 31). FIG. 31 Local Area Connection Properties 4. In the Local Area Connection Properties window (FIG. 31) under the General tab, select Internet Protocol (TCP/IP) and click on Properties to open the Internet Protocol (TCP/IP) Properties window.

  • Page 46: Configure A Virtual Netlinx Master Via Usb

    Configuring Communication Systems Settings page of the Protected Settings menu, as shown in FIG. 33. (For more information, refer to the Protected Setup Pages section on page 55.) FIG. 33 IP address location on the System Settings Page Under Subnet mask, set the subnet mask to 255.255.255.0. Do not enter the Gateway or DNS information.
  • Page 47 2. In NetLinx Studio, select Settings > Master Communication Settings from the Main menu to open the Master Communication Settings dialog (FIG. 34). FIG. 34 Master Communications Settings dialog box 3. Click the Communications Settings button to open the Communications Settings dialog (FIG. 35). FIG.

  • Page 48: Connecting To The Netlinx Master Via Ethernet (Mvp-5150 Only)

    Virtual NetLinx Master Settings dialog box 7. Select the IP Address for the AMX USB device in the Available Connections section. The IP address will appear in the Current Connection field. Click OK to save the settings and close the window.

  • Page 49: Master Connection To A Virtual Master Via Ethernet

    3. Set the Master Port and select Done. 4. If you enabled password security on your Master, set the username and password within the device. 5. Select the blank field Username to open the keyboard. 6. Set the Username and select Done. 7.
  • Page 50 By selecting Auto, the URL field becomes read-only (grey) because the panel pulls this value directly from the communicating target Master, virtual or not. A Virtual Master system value can be set within the active AMX software applications such as NetLinx Studio, TPD4, or IREdit.
  • Page 51 18. Press the on-screen Reboot button to save any changes and restart the panel. The panel will now be connected to the master. 19. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System. The default System value is one.
  • Page 52 Configuring Communication MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 53: Setup Pages

    Setup Pages Both the MVP-5100 and MVP-5150 feature on-board Setup pages. Use the options in the Setup pages to access panel information and make various configuration changes. To access the Setup pages, press the reset button and hold for 3 to 5 seconds (FIG. 40). FIG.
  • Page 54 Setup Pages Setup Page (Cont.) Connection Status: Display Timeout: Inactivity Page Flip Timeout: Panel Brightness: Displays whether the panel has external communication, as well as the encryption status of the Master, the connection type (Ethernet or USB), and to which System the panel is connected. •...

  • Page 55: Navigation Buttons

    Navigation Buttons The following Navigation buttons (FIG. 42) appear on the left side of the Setup page: FIG. 42 Setup Page Navigation Buttons Protected Setup Pages Information on the Protected Setup pages is available on page 55. MVP-5100/5150 Modero Viewpoint Touch Panels Press to access the Protected Setup pages.

  • Page 56: Information Button

    Setup Pages Information Button The Information button allows access of both the Project Information page, which contains data on the TPDesign4 file being used with the MVP-5100, and the Panel Information page, which contains detailed information on the panel itself. To access these pages: 1.
  • Page 57 Receivers tab). • For example, if you set the AMX IR 38K Port to 7 and then put a button on the panel with a channel code of 5 and a port of 7, it will trigger the IR code in slot 5 of the AMX IR 38K Port.

  • Page 58: Panel Information Page

    Setup Pages Panel Information Page The Panel Information page provides detailed panel information (FIG. 44). FIG. 44 Panel Information page Features on this page include: Panel Information Page Back: Connection Status icon: Panel Type: Firmware Version: Setup Port: High Port: High Address: High Channel: High Level:...

  • Page 59: Time & Date Settings Page

    Time & Date Settings Page The options on the Time & Date Settings page (FIG. 45) allows setting and adjusting of time and date information on the NetLinx Master. If the time and/or date on the Master is modified, all connected devices will be updated to reflect the new information.

  • Page 60: Audio Settings Page

    Setup Pages Audio Settings Page The Audio Settings page allows adjustment of volume levels and panel sounds settings (FIG. 46). FIG. 46 Audio Settings pages Features on these pages include: Audio Settings Page Back: Connection Status icon: Default Panel Sounds: Saves all changes and returns to the previous page.

  • Page 61: Battery Settings Page

    Battery Settings Page The options on the Battery Settings page allow setting of power warning preferences and battery status information, and adjustment of the display times for battery warnings (FIG. 47). FIG. 47 Battery page Features on this page include: Battery Page Back: Connection Status icon:...
  • Page 62 Setup Pages MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 63: Protected Setup Pages

    Protected Setup Pages The Protected Setup page (FIG. 48) provides secured access to advanced panel configuration options, including communication and security settings. The Protected Setup page is accessed through the Setup page (please refer to the Setup Pages section on page 45). To access the Protected Setup pages: 1.
  • Page 64 • Remove User Pages - Removes all TPD4 touch panel pages currently on the panel, including the pre-installed AMX Demo pages. This option invokes a Confirmation dialog, prompting you to confirm your selection before removing the panel pages.

  • Page 65: Rebooting And Shutting Down The Touch Panel

    Protected Setup Pages The Protected Setup page for the MVP-5100 is slightly different, as some of the functions are disabled (FIG. 50). The particular functions that are disabled are explained in detail in the Protected Setup Navigation Buttons section on page 58. FIG.

  • Page 66: Protected Setup Navigation Buttons

    Protected Setup Pages Protected Setup Navigation Buttons The Protected Setup Navigation Buttons (FIG. 51) appear on the left edge of the Protected Setup page. The Navigation Buttons for the MVP-5100 have different functionality than those for the MVP-5150, as shown below. FIG.

  • Page 67: System Settings Page

    System Settings Page The System Settings page (FIG. 53) displays sets the NetLinx Master’s communication settings. FIG. 53 System Settings page The elements of this page include: System Settings Page Elements Back: Connection Status icon: IP Settings: Master Connection: Type MVP-5100/5150 Modero Viewpoint Touch Panels Saves all changes and returns to the previous page.
  • Page 68 Protected Setup Pages System Setting Page Elements (Cont.) Mode System Number Master IP/URL Master Port Number Username/Password NDP Name Refer to the Step 3: Choose a Master Connection Mode section on page 33 for more detailed information on using the System Settings page. Cycles between the connection modes: URL, Listen, NDP(UDP,) URL(UDP), and Auto.

  • Page 69: Wireless Settings Page (Mvp-5150 Only)

    Wireless Settings Page (MVP-5150 Only) Use the options on the Wireless Settings page (FIG. 54) to configure communication settings for the wireless CF card (802.11b/g), and read the device number assigned to the panel. Since the MVP-5100 does not have wireless capability, the button to this page is greyed out in the MVP-5100 Protected Settings page.
  • Page 70 • Refer to the EAP-PEAP Settings section on page 74 for further details. • For information on uploading a certificate file, refer to the AMX Certificate Upload Utility section on page 162.
  • Page 71 • Refer to the EAP-TTLS Settings section on page 76 for further details. • For information on uploading a certificate file, refer to the AMX Certificate Upload Utility section on page 162. This button opens the EAP-TLS Settings page (FIG. 65 on page 78).

  • Page 72: Wireless Security

    Protected Setup Pages Wireless Security The options on the Wireless Security section (FIG. 55) include the wireless security methods supported by the NXA-WC80211GCF Wi-Fi card. These security methods incorporate WPA, WPA2, and EAP technology, some of which require the upload of unique certificate files to a target panel. Refer to the Appendix B: Wireless Technology section on page 156 for further information.

  • Page 73: Open (Clear Text) Settings

    • Make sure this setting is the same for all points in your wireless network. • NXA-WAP250Gs use AMX as their default SSID. • If this field is left blank, the panel will attempt to connect to the first available WAP.

  • Page 74: Static Wep Settings

    • Make sure this setting is the same for all points in your wireless network. • NXA-WAP250Gs use AMX as their default SSID. • If this field is left blank, the panel will attempt to connect to the first available WAP.

  • Page 75: Wpa-Psk Settings

    Static WEP Settings (Cont.) WEP Keys: Current Key: Authentication: Save/Cancel: Refer to the Configuring Wireless Network Access (MVP-5150 Only) section on page 23 and the Using the Site Survey tool section on page 26 for further details on these security options. WPA-PSK Settings Press the WPA-PSK button to opens the WPA-PSK dialog (FIG.

  • Page 76: Eap Security & Server Certificates - Overview

    • Make sure this setting is the same for all points in your wireless network. • NXA-WAP250Gs use AMX as their default SSID. • If this field is left blank, the panel will attempt to connect to the first available WAP.
  • Page 77 Protected Setup Pages All three of these certificate-using security methods are documented in the following sections. EAP Authentication goes a step beyond simply encrypting data transfers, but also requires that a set of credentials be validated before the client (panel) is allowed to connect to the rest of the network (FIG.

  • Page 78: Eap-Leap Settings

    Protected Setup Pages EAP-LEAP Settings Press the EAP-LEAP button to open the EAP-LEAP Settings page (FIG. 60). FIG. 60 Wireless Settings page - EAP-LEAP Settings EAP (Extensible Authentication Protocol) is an Enterprise authentication protocol that can be used in both wired and wireless network environments. EAP requires the use of an 802.1x Authentication Server, also known as a Radius server.
  • Page 79 This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as jdoe@amx.com. Opens an on-screen keyboard. Enter the network password string specified...

  • Page 80: Eap-Fast Settings

    This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as: jdoe@amx.com. MVP-5100/5150 Modero Viewpoint Touch Panels...
  • Page 81 PAC shared secret credentials for use in authentication. In this case, the IT department must create a PAC file and then transfer it into the panel using the AMX Certificate Upload application. Note: Even when automatic provisioning is enabled, the PAC certificate is only downloaded the first time that the panel connects to the RADIUS server.

  • Page 82: Eap-Peap Settings

    Protected Setup Pages EAP-PEAP Settings Press the EAP-PEAP button to open the EAP-PEAP Settings page (FIG. 63). FIG. 63 Wireless Settings page - EAP-PEAP Settings PEAP (Protected Extensible Authentication Protocol) was developed as a way to securely transmit authentication information, such as passwords, over a wireless network environment. PEAP uses only server-side public key certificates and therefore does not need a client (panel) certificate which makes the configuration and setup easier.
  • Page 83 This works in tandem with the Password string, which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as jdoe@amx.com. Opens an on-screen keyboard to enter the network password string specified...

  • Page 84: Eap-Ttls Settings

    • Make sure this setting is the same for all points in the wireless network. • NXA-WAP250Gs use AMX as their default SSID. • With EAP security, the SSID of the WAP must be entered. If it is left blank, the panel will try to connect to the first access point detected that supports EAP.
  • Page 85 This works in tandem with the Password string which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as: jdoe@amx.com. Opens an on-screen keyboard. Enter an IT provided alpha-numeric string which (similar to the username) used as the identity, but that does not represent a real user.

  • Page 86: Eap-Tls Settings

    This works in tandem with the Password string, which is similar to the password entered to gain access to a secured workstation. Typically, this is in the form of a username such as: jdoe@amx.com. MVP-5100/5150 Modero Viewpoint Touch Panels...
  • Page 87 EAP-TLS Settings (Cont.) Certificate Authority: Client Certificate: Private Key: Private Key password: Save/Cancel: Refer to the EAP Authentication section on page 160 for further details on these security options. Refer to the Using the Site Survey tool section on page 26 for more information on using this feature.

  • Page 88: Client Certificate Configuration

    Format is: PKCS12 First file contains the client certificate, second file contains the private key. Format is: PKCS12 AMX supports the following security certificates PEM (Privacy Enhanced Mail) DER (Distinguished Encoding Rules) PKCS12 (Public Key Cryptography Standard #12) PKCS12 files are frequently generated by Microsoft certificate applications.

  • Page 89: Calibration Page

    Calibration Page The Calibration page (FIG. 66) allows you to calibrate the touch panel for accurate button selection. FIG. 66 Calibration page 1. Press and hold the reset button for 6 seconds to access the Calibration page (see FIG. 48). 2.

  • Page 90: Other Settings

    Protected Setup Pages Other Settings Press the Other Settings button to display the two settings options for Cache and Password. Press one of the options within three seconds, or the two options buttons will slide back behind the Other Settings button.

  • Page 91: Password Settings Page

    Password Settings Page The options on the Password Settings page (FIG. 68) allow assignment of passwords required for users to access the Protected Setup page, and to release the device from a MVP-WCS-52 Charging Station. FIG. 68 Password Setup page Features on this page include: Password Setup Page Back:...
  • Page 92 Protected Setup Pages The User Access section allows the Administrator to control access of all individuals using or attempting to use the MVP-5100. From this section, new users may be given access rights to the device; however, they will NOT be given access to the Protected Settings page. Only one of the main passwords may be used to access the Protected Settings page.

  • Page 93: Upgrading Firmware

    (FG10-5965) for programming, firmware updates, and touch panel file transfer between the PC and the target device. If a programming cable is not available, it may be purchased from www.amx.com. The Mini-USB port for the connector is located on the left side of the device as viewed from the front.

  • Page 94: Step 2: Prepare Studio For Communication Via The Usb Port

    1. From the Start menu in Windows XP, open the Network Connections dialog (Start > Settings > Network Connections > Local Area Connection). 2. Look for the Local Area Connection reading "Local Area Connection, AMX USB Device Link" and double-click on it to open the Local Status.
  • Page 95 10. Click the Communications Settings... button to open the Communications Settings dialog box (FIG. 70). FIG. 70 Communications Settings dialog box 11. Click on the NetLinx Master radio button from the Platform Selection section. 12. Click on the Virtual Master radio box from the Transport Connection Option section to configure the PC to communicate directly with a panel.

  • Page 96: Step 3: Confirm And Upgrade The Firmware Via The Usb Port

    The panel-specific firmware is shown on the right of the listed panel. Download the latest firmware file from www.amx.com and then save the Kit file to your computer. Note that each kit file is intended for download to its corresponding panel.
  • Page 97 15. Confirm that the panel has been properly updated to the correct firmware version. Verify you have downloaded the latest firmware file from www.amx.com and then save the Kit file to your computer. MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 98: A Special Note For Network Interface Connections

    Upgrading Firmware A Special Note for Network Interface Connections Due to any USB connection to your PC being made through a Network Interface Connection (NIC), Windows will automatically make any new NIC connection the Primary connection. If this happens, the USB address of 12.0.0.x will show up across the PC’s network switches as the PC’s source address.
  • Page 99 3. From the Advanced menu, select Advanced Settings... to open the Advanced Settings window (FIG. 75). FIG. 75 Advanced Settings window 4. Under the Adapters And Bindings tab, the user needs to make sure the Local Area Connection is not at the top of the Connections list.
  • Page 100 Upgrading Firmware FIG. 77 Bindings for Local area list detail 6. When finished, click OK to close the Advanced Settings window and save all changes. MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 101: Uploading Ir Codes To The Mvp-5100

    IR codes is vital. To ensure that the IR codes installed on the device are the most suitable, use NetLinx Studio to upload newly available codes via the AMX IRN database. Installation of IR files on the MVP-5100 requires use of the latest version of NetLinx Studio, available from www.amx.com.
  • Page 102 Upgrading Firmware 4. When the IR file appears in the Workspace Tree, right-click on the file and select Device Mapping... to open the Device Mapping window (FIG. 79). FIG. 79 Device Mapping window 5. Click the Map button to open the Enter DPS window (FIG. 80) and enter the device number, port number, and system number for the touch panel.

  • Page 103: Adding An Existing Ir File To Netlinx Studio

    7. From the main menu, select Tools > Firmware Transfers > Send To NetLinx Device... to open the Send to NetLinx Device window (FIG. 81). FIG. 81 Send to NetLinx Device window 8. Select the file to be transferred and click Close when finished. Adding an existing IR file to NetLinx Studio To add an existing IR file to NetLinx Studio: 1.

  • Page 104: Adding An Amx Ir Database File To Netlinx Studio

    A Database window. The pane above the database directory tree will read ***AMX Directory Database***. 2. From the directory tree, click on the AMX folder to open it. Select the appropriate IR file, and the Selected IR Information pane will display the available information on the file (FIG. 83).
  • Page 105 4. In the File Properties window (FIG. 85), verify the Identifier and Description information (in the only two fields with editable data) and click OK. FIG. 85 File Properties window 5. The selected IR file now appears in the NetLinx Studio Workspace (FIG. 86). FIG.

  • Page 106: Adding A Personal Ir Database File To Netlinx Studio

    Upgrading Firmware Adding a personal IR Database file to NetLinx Studio To choose an IR file from a personal IR file database: 1. In the NetLinx Studio Workspace, select Add From User IR Database... to open the Select IRN User Database window (FIG.

  • Page 107: Programming

    Programming Overview You can program the MVP-5100 and MVP-5150, using the commands in this section, to perform a wide variety of operations using Send_Commands and variable text commands. A device must first be defined in the NetLinx programming language with values for the Device: Port: System (in all programming examples - Panel is used in place of these values and represents all Modero panels).
  • Page 108 Programming Page Commands (Cont.) If the flag is set, the popup will return to its default location on show instead of its last drag @PDR location. Set the popup location reset flag. Syntax: Variable: Example: Popup1 will return to its default location when turned On. Syntax: @PHE Set the hide effect...
  • Page 109 Page Commands (Cont.) If the page name is empty, the current page is used (see example 2). If the popup page is @PPF part of a group, the whole group is deactivated. This command works in the same way as Deactivate a the ’Hide Popup’...
  • Page 110 Programming Page Commands (Cont.) A Modal popup page, when active, only allows you to use the buttons and features on that @PPM popup page. All other buttons on the panel page are inactivated. Set the modality of a specific Syntax: popup page to Modal or Variable:...
  • Page 111 Page Commands (Cont.) Syntax: @PSE Set the show effect for the Variable: specified popup page to the named show effect. Example: Sets the Popup1 show effect name to ’Slide from Left’. Only 1 coordinate is ever needed for an effect; however, the command will specify both. @PSP This command sets the location at which the effect will begin.
  • Page 112 Programming Page Commands (Cont.) If the page name is empty, the current page is used (see example 2). If the popup page is PPOF part of a group, the whole group is deactivated. This command works in the same way as Deactivate a the ’Hide Popup’...

  • Page 113: Programming Numbers

    Programming Numbers The following information provides the programming numbers for colors, fonts, and borders. Colors can be used to set the colors on buttons, sliders, and pages. The lowest color number represents the lightest color-specific display; the highest number represents the darkest display. For example, 0 represents light red, and 5 is dark red.
  • Page 114 Programming RGB Values for all 88 Basic Colors (Cont.) Index No. Name Very Light Cyan Light Cyan Cyan Medium Cyan Dark Cyan Very Dark Cyan Very Light Aqua Light Aqua Aqua Medium Aqua Dark Aqua Very Dark Aqua Very Light Blue Light Blue Blue Medium Blue...

  • Page 115: Font Styles And Id Numbers

    Courier New Courier New Courier New Courier New Courier New AMX Bold AMX Bold AMX Bold Fonts must be imported into a TPDesign4 project file. The font ID numbers are assigned by TPDesign4. These values are also listed in the Generate Programmer’s Report.

  • Page 116: Border Styles And Programming Numbers

    The following number values cannot be used for programming purposes when changing border styles. TPD4 border styles may ONLY be changed by using the name. TPD4 Border Styles by Name Border styles None AMX Elite -L AMX Elite -M AMX Elite -S Bevel -L Bevel -M...
  • Page 117 TPD4 Border Styles by Name (Cont.) Border styles Diamond 185 Diamond 195 Double Bevel -L Double Bevel -M Double Bevel -S Double Line Fuzzy Glow-L Glow-S Help Down Neon Active -L Neon Active -S Neon Inactive -L Neon Inactive -S Oval H 60x30 Oval H 100x50 Oval H 150x75...
  • Page 118 Programming TPD4 Border Styles by Name (Cont.) Border styles Menu Left Rounded 55 Menu Left Rounded 65 Menu Left Rounded 75 Menu Left Rounded 85 Menu Left Rounded 95 Menu Left Rounded 105 Menu Left Rounded 115 Menu Left Rounded 125 Border styles Menu Left Rounded 135 Menu Left Rounded 145...

  • Page 119: Button Commands

    "^" Button Commands These Button Commands are used in NetLinx Studio and are case insensitive. All commands that begin with "^" have the capability of assigning a variable text address range and button state range. A device must first be defined in the NetLinx programming language with values for the Device: Port : System (in all programming examples - Panel is used in place of these values).
  • Page 120 Programming "^" Button Commands (Cont.) Same format as ^UNI. ^BAU Append Syntax: unicode text. Variable: Example: Appends Unicode text '00770062' to the button’s OFF state. Only if the specified border color is not the same as the current color. ^BCB Set the border Note: Color can be assigned by color name (without spaces), number or R,G,B value color to the...
  • Page 121 "^" Button Commands (Cont.) Only if the specified text color is not the same as the current color. ^BCT Set the text color Note: Color can be assigned by color name (without spaces), number or R,G,B value to the specified (RRGGBB or RRGGBBAA).
  • Page 122 Programming "^" Button Commands (Cont.) Syntax: ^BIM Set the input mask for the Variable: specified address. Example: Sets the input mask to ten ’A’ characters, that are required, to either a letter or digit (entry is required). The maximum number of lines to remove is 240. A value of 0 will display the incoming ^BLN video signal unaffected.
  • Page 123 "^" Button Commands (Cont.) Note that the source is a single button state. Each state must be copied as a separate ^BMC command. The <codes> section represents what attributes will be copied. All codes are Button copy 2 char pairs that can be separated by comma, space, percent or just ran together. command.
  • Page 124 Programming "^" Button Commands (Cont.) Syntax: ^BMF Set any/all button parameters by Variables: sending embedded codes and data. "'^BMF-<vt addr range>,<button states range>,<data>'" variable text address char array = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons 1 = Off state and 2 = On state).
  • Page 125 "^" Button Commands (Cont.) ^BMF (Cont.) Example: Sets the button OFF state as well as the Border, Fill Color, Border Color, Text Color, and Bitmap. MVP-5100/5150 Modero Viewpoint Touch Panels For some of these commands and values, refer to the RGB Values for all 88 Basic Colors table on page 105.
  • Page 126 Programming "^" Button Commands (Cont.) Mask image is used to crop a borderless button to a non-square shape. This is typically ^BMI used with a bitmap. Set the button mask image. Syntax: Variable: Example: Sets the button with variable text 530 ON/OFF state mask image to 'newmac.png'. If this value is set to zero (0), the text area has no max length.
  • Page 127 "^" Button Commands (Cont.) Syntax: ^BNN Set the TakeNote network name for Variable: the specified Addresses. Example: Sets the TakeNote button network name to 192.168.169.99. Syntax: ^BNT Set the TakeNote network port for Variable: the specified Addresses. Example: Sets the TakeNote button network port to 5000. The button opacity can be specified as a decimal between 0 - 255, where zero (0) is ^BOP invisible and 255 is opaque, or as a HEX code, as used in the color commands by...
  • Page 128 Sets the border by number (#10) to those buttons with the variable text range of 500-504 & 510-515. Sets the border by name (AMX Elite) to those buttons with the variable text range of 500-504 & 510-515. The border style is available through the TPDesign4 border-style drop-down list. Refer to theTPD4 Border Styles by Name table on page 108 for more information.
  • Page 129 "^" Button Commands (Cont.) Only if the specified border is not the same as the current border. The border names are ^BRD available through the TPDesign4 border-name drop-down list. Set the border of a button state/ Syntax: states. Variable: Example: Sets the border by name (Quad Line) to those buttons with the variable text range of 500-504 &...
  • Page 130 Programming "^" Button Commands (Cont.) Syntax: ^BVL Log-On/Log-Off the computer Variable: control connection. Example: Logs-off the computer control connection of the button. Syntax: ^BVN Set the computer control remote Variables: host for the specified address. Example: Sets the remote host to '191.191.191.191' for the specific computer control button. Syntax: ^BVP Set the network...
  • Page 131 "^" Button Commands (Cont.) Syntax: ^CPF Clear all page flips from a button. Variable: Example: Clears all page flips from the button. Syntax: ^DLD Set the disable cradle LED flag. Variable: Example: Disables the cradle LEDs. Syntax: ^DPF Delete page flips from button if it Variable: already exists.
  • Page 132 Programming "^" Button Commands (Cont.) Font ID numbers are generated by the TPDesign4 programmers report. ^FON Set a font to a Syntax: specific Font ID value for those Variable: buttons with a defined address range. Example: Sets the font size to font ID #4 for the On and Off states of buttons with the variable text range of 500-504 &...
  • Page 133 "^" Button Commands (Cont.) Syntax: ^GLH Change the bargraph upper Variable: limit. Example: Changes the bargraph upper limit to 1000. Syntax: ^GLL Change the bargraph lower Variable: limit. Example: Changes the bargraph lower limit to 150. Syntax: ^GRD Change the bargraph Variable: ramp-down time...
  • Page 134 Programming "^" Button Commands (Cont.) Slider names and cursor names can be found in the TPDesign4 slider name and cursor ^GSN drop-down list. Change the bargraph slider Syntax: name or joystick cursor name. Variable: Example: Changes the bargraph slider name or the Joystick cursor name to ’Ball’. Syntax: ^ICO Set the icon to a...
  • Page 135 "^" Button Commands (Cont.) The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative ^JSB to the upper left corner of the button. Set bitmap/ picture alignment Syntax: using a numeric keypad layout for those buttons with Variable: a defined address range.
  • Page 136 Programming "^" Button Commands (Cont.) The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative ^JST to the upper left corner of the button. Set text alignment using a Syntax: numeric keypad layout for those buttons with a Variable: defined address...
  • Page 137 "^" Button Commands (Cont.) The Text Effect is specified by name and can be found in TPD4. You can also assign the ^TEC color by name or RGB value (RRGGBB or RRGGBBAA). Set the text effect color for the Syntax: specified addresses/states Variable:...

  • Page 138: Miscellaneous Mvp Strings Back To The Master

    Programming "^" Button Commands (Cont.) For the ^UNI command (%UN and ^BMF command), the Unicode text is sent as ^UNI ASCII-HEX nibbles. Set Unicode text. Syntax: Variable: Example: Sets the button’s unicode character to ’A’. Note: To send the variable text ’A’ in unicode to all states of the variable text button 1, (for which the character code is 0041 Hex), send the following command: Note: Unicode is always represented in a HEX value.

  • Page 139: Text Effects Names

    MVP Panel Lock Passcode Commands (Cont.) Syntax: ^LPR Remove a given user from the User Variable: Access Passwords list on the Password Example: Setup page. Remove user named ’Robert’ from the User Access Password list on the Password Setup page. Refer to the Other Settings section on page 82 for more information.

  • Page 140: Button Query Commands

    Programming Text Effects (Cont.) • Soft Drop Shadow 1 with outline • Soft Drop Shadow 2 with outline • Soft Drop Shadow 3 with outline • Soft Drop Shadow 4 with outline • Soft Drop Shadow 5 with outline • Soft Drop Shadow 6 with outline •...
  • Page 141 All custom events have the following 7 fields: Custom Event Fields Field Uint Flag slong value1 slong value2 slong value3 string text text length (string encode) These fields are populated differently for each query command. The text length (String Encode) field is not used in any command.
  • Page 142 Programming Button Query Commands (Cont.) Syntax: ?BCF Get the current fill color. Variable: Example: Gets the button 'OFF state' fill color information. The result sent to the Master would be: Syntax: ?BCT Get the current text color. Variable: Example: Gets the button 'OFF state' text color information. The result sent to Master would be: "'?BCF-<vt addr range>,<button states range>'"...
  • Page 143 Button Query Commands (Cont.) Syntax: ?BMP Get the current bitmap name. Variable: Example: Gets the button 'OFF state' bitmap information. The result sent to the Master would be: Syntax: ?BOP Get the overall button opacity. Variable: Example: Gets the button 'OFF state' opacity information. The result sent to the Master would be: MVP-5100/5150 Modero Viewpoint Touch Panels "'?BMP-<vt addr range>,<button states range>'"...
  • Page 144 Programming Button Query Commands (Cont.) Syntax: ?BRD Get the current border name. Variable: Example: Gets the button 'OFF state' border information. The result sent to the Master would be: Syntax: ?BWW Get the current word wrap flag Variable: status. Example: Gets the button 'OFF state' word wrap flag status information.
  • Page 145 Button Query Commands (Cont.) Syntax: ?FON Get the current font index. Variable: Example: Gets the button 'OFF state' font type index information. The result sent to the Master would be: Syntax: ?ICO Get the current icon index. Variable: Example: Gets the button 'OFF state' icon index information. The result sent to the Master would be: MVP-5100/5150 Modero Viewpoint Touch Panels "'?FON-<vt addr range>,<button states range>'"...
  • Page 146 Programming Button Query Commands (Cont.) Syntax: ?JSB Get the current bitmap Variable: justification. Example: Gets the button 'OFF state' bitmap justification information. The result sent to the Master would be: Syntax: ?JSI Get the current icon Variable: justification. Example: Gets the button 'OFF state' icon justification information. The result sent to the Master would be: "'?JSB-<vt addr range>,<button states range>'"...
  • Page 147 Button Query Commands (Cont.) Syntax: ?JST Get the current text justification. Variable: Example: Gets the button 'OFF state' text justification information. The result sent to the Master would be: Syntax: ?TEC Get the current text effect color. Variable: Example: Gets the button 'OFF state' text effect color information. The result sent to the Master would be: MVP-5100/5150 Modero Viewpoint Touch Panels "'?JST-<vt addr range>,<button states range>'"...
  • Page 148 Programming Button Query Commands (Cont.) Syntax: ?TEF Get the current text effect name. Variable: Example: Gets the button 'OFF state' text effect name information. The result sent to the Master would be: Syntax: ?TXT Get the current text information. Variable: Example: Gets the button 'OFF state' text information.

  • Page 149: Panel Runtime Operations

    Panel Runtime Operations Serial Commands are used in the AxcessX Terminal Emulator mode. These commands are case insensitive. Panel Runtime Operation Commands Syntax: ABEEP Output a single beep even if beep Example: is Off. Outputs a beep of duration 1 beep even if beep is Off. Syntax: ADBEEP Output a double...
  • Page 150 Programming Panel Runtime Operation Commands (Cont.) Keypad string is set to null on power up and is stored until power is lost. The Prompt Text @AKP is optional. Pop up the keypad icon and Syntax: initialize the text string to that Variables: specified.
  • Page 151 Panel Runtime Operation Commands (Cont.) Pops up the keypad icon and initializes the text string to that specified. The Prompt Text is @EKP optional. Extend the Keypad. Syntax: Variables: Example: Pops up the Keypad and initializes the text string '33333333' with prompt text 'Enter Password'.
  • Page 152 Programming Panel Runtime Operation Commands (Cont.) Syntax: @SOU Play a sound file. Variables: Example: Plays the 'Music.wav' file. Pops up the keypad icon and initializes the text string to that specified. The Prompt Text is @TKP optional. Present a telephone Syntax: keypad.

  • Page 153: Input Commands

    Input Commands These Send Commands are case insensitive. Input Commands Syntax: ^CAL Put panel in calibration mode. Example: Puts the panel in calibration mode. Syntax: ^KPS Set the keyboard Variable: passthru. Example: Sets the keyboard passthru to the Master. Option 5 sends keystrokes directly to the Master via the Send Output String mechanism.

  • Page 154: Embedded Codes

    Programming Embedded codes The following is a list of G4 compatible embedded codes: Embedded Codes Decimal numbers Hexidecimal values Virtual keystroke ($08) Backspace ($0D) Enter ($1B) ($80) CTRL key down ($81) ALT key down ($82) Shift key down ($83) ($84) ($85) ($86) ($87)

  • Page 155: Panel Setup Commands

    Panel Setup Commands These commands are case insensitive. Panel Setup Commands Syntax: ^MUT Set the panel mute state. Variable: Example: Sets the panel’s master volume to mute. @PWD sets the level 1 password only. @PWD Set the page flip Syntax: password.
  • Page 156 Programming MVP-5100/5150 Modero Viewpoint Touch Panels...

  • Page 157: Battery Life And Replacement

    Battery Life and Replacement Overview The battery powering the MVP-5100 and MVP-5150 is designed for upwards of 300 deep discharge rechargings. Regular shallow rechargings will extensively increase expected battery life, and the device should be stored in either the Table Charging Station or the Wall Charging Station when not in use to keep it at an optimum charge.

  • Page 158: Battery Replacement

    Battery Life and Replacement Battery Replacement The touch panel's battery is intended to last the life of the device, but it may be upgraded for additional run time. In cases where the battery has reached its effective end of life, it may be replaced with the MVP-BP-52 Battery Pack Kit (FG5966-20).

  • Page 159: Appendix A: Text Formatting

    Appendix A: Text Formatting Text Formatting Codes for Bargraphs/Joysticks Text formatting codes for bargraphs provide a mechanism to allow a portion of a bargraphs text to be dynamically provided information about the current status of the level (multistate and traditional). These codes are entered into the text field along with any other text.

  • Page 160: Text Area Input Masking

    Appendix A: Text Formatting Text Area Input Masking Text Area Input Masking may be used to limit the allowed/correct characters that are entered into a text area. For example, in working with a zip code, a user could limit the entry to a max length of only 5 characters;...

  • Page 161: Input Mask Ranges

    Refer to the following Send_Commands for more detailed information: • ^BIM page 114). • ^BMF ^BMF section on page 116). Input mask ranges These ranges allow a user to specify the minimum and maximum numeric value for a field. Only one range is allowed per field.

  • Page 162: Input Mask Output Examples

    Appendix A: Text Formatting A keyboard entry using normal text entry is straightforward. However, once an input mask is applied, the behavior of the keyboard needs to change to accommodate the input mask's requirement. When working with masks, any literal characters in the mask will be "skipped" by any cursor movement, including cursor, backspace, and delete keys.

  • Page 163: Url Resources

    URL indicates that the protocol in use is http (HyperText Transport Protocol) and that the information resides on a host machine named www.amx.com. The image on that host machine is given an assignment (by the program) name of company-info-home.asp (Active Server Page).

  • Page 164: Appendix B: Wireless Technology

    Appendix B: Wireless Technology Appendix B: Wireless Technology Overview of Wireless Technology 802.11b/2.4 GHz and 802.11a/5 GHz are the two major WLAN standards and both operate using radio frequency (RF) technology. Together the two standards are together called Wi-Fi and operate in frequency bands of 2.4 GHz and 5 GHz respectively. The 802.11b specification was the first to be finalized and reach the marketplace.

  • Page 165: Terminology

    (CA) is a trusted external third party which "signs" or validates the certificate. When a certificate has been signed, it gains some cryptographic properties. AMX supports the following security certificates within three different formats: Typical certificate information can include the following items:...
  • Page 166 Appendix B: Wireless Technology Short for Wired Equivalent Privacy, WEP is a scheme used to secure wireless networks (Wi-Fi). A wireless network broadcasts messages using radio which are particularly susceptible to hacker attacks. WEP was intended to provide the confidentiality and security comparable to that of a traditional wired network. As a result of identified weaknesses in this scheme, WEP was superseded by Wi-Fi Protected Access (WPA), and then by the full IEEE 802.11i standard (also known as WPA2).
  • Page 167 WPA2 Also know as IEEE 802.11i, this is an amendment to the 802.11 standard specifying security mechanisms for wireless networks. The 802.11i scheme makes use of the Advanced Encryption Standard (AES) block cipher; WEP and WPA use the RC4 stream cipher. The 802.11i architecture contains the following components: 802.1X for authentication (entailing the use of EAP and an authentication server), RSN for keeping track of associations, and AES-based CCMP to provide confidentiality,...

  • Page 168: Eap Authentication

    Appendix B: Wireless Technology EAP Authentication EAP (Extensible Authentication Protocol) is an Enterprise authentication protocol that can be used in both a wired and wireless network environment. EAP requires the use of an 802.1x Authentication Server, also known as a RADIUS server. Although over 40 different EAP methods are currently defined, the current internal Modero 802.11g wireless card and accompanying firmware only support the following EAP methods (listed from simplest to most complex): EAP-LEAP (Cisco Light EAP)

  • Page 169: Eap Communication Overview

    EAP communication overview EAP Authentication goes a step beyond just encrypting data transfers, but also requires that a set of credentials be validated before the client (panel) is allowed to connect to the rest of the network (FIG. 91). Below is a description of this process. It is important to note that no user intervention is necessary during this process.

  • Page 170: Amx Certificate Upload Utility

    NetLinx Studio and TPDesign4 software application installations. 1. Install the latest AMX USB LAN LINK driver onto your computer by installing the latest versions of either TPDesign4 or NetLinx Studio2. This USB driver prepares your computer for proper communication with the device.
  • Page 171 6. Select the IP Address that corresponds to the virtual IP Address assigned to the USB connection port on the computer. The default is 12.0.0.2. 7. Navigate to the Add IP Address field at the bottom-left of the interface and enter a value of 1 greater than the virtual USB IP Address.

  • Page 172: Appendix C: Troubleshooting

    To keep the battery from being damaged from operating at too low a level, the firmware places it into a protected state. The panel must have the latest firmware. If it doesn’t, the firmware can be found at www.amx.com >Tech Center > Firmware Files.> Modero.

  • Page 173: Device Isn't Appearing In The Online Tree Tab

    Device Isn’t Appearing In The Online Tree Tab 1. Verify that the System number is the same on both the NetLinx Project Navigator window and the System Settings page on the device. 2. Verify the proper NetLinx Master IP and connection methods entered into the Master Connection section of the System Settings page.

  • Page 174: Only One Modero Panel In My System Shows Up

    Compact Flash. Panel will not boot, or gets stuck on "AMX" splash screen. Other problems also started after downloading to a new panel or a panel with a TPD4 file that takes up a considerable amount of the available Compact Flash.
  • Page 175 Appendix MVP-5100/5150 Modero Viewpoint Touch Panels...
  • Page 176 It’s Your World - Take Control™ 3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com...

This manual is also suitable for:

Modero mvp-5100

Table of Contents

Save PDF
