Figure 5
VPA-CHG (power supply and
VPT-CP Fast-Cycle Battery
Charger for VPA-BP)
ViewPoint Wireless Touch Panels
Red LED indicates
charging
Charging pins
12 VDC Power
Supply
Green LED
indicates battery is
charged
VPA-CHG Fast
Cycle battery
charger
Power supply
connection
Installation
9
