Figure 144
Function show button and
slider example
Note
Refer to the Function show
subsection for more
information.
Note
G3 firmware allows up to
1020 button combinations.
Note
Level settings apply only to
Joystick buttons (Joystick and
Video Joystick button types),
and Bargraph buttons
(Horizontal and Vertical
Bargraph button types).
ViewPoint Wireless Touch Panels
As shown in Figure 144, the upper-left corner of a button shows a base device
number followed by a channel code number. The bottom-right corner of a button
shows the variable text number followed by the variable text channel.
Base
device
3, 132
Button
LIGHT
PANEL
Variable text
device number
Text channel
The G3 firmware is designed to allow you up to 255 channels per device layer.
VAR TEXT − DEV
the current button and touch panel page. The device range is 1 through 4.
VAR TEXT − CHAN
channel code for the current button. The channel code range is from 1
through 255. Record the channel code settings if you want to create duplicate
buttons and their functions on another page. If AUTO ASSIGN is enabled in
the Protected Setup page, the touch panel prompts you to automatically or
manually assign the channel code. Select YES to allow the touch panel to
automatically assign the lowest available channel number.
LEVEL − DEV
current button and touch panel page. The device range is 1 through 4.
LEVEL − NUM
current button. The number code range is 1 through 8 except for bargraphs
and joysticks, where the range is from 1 through 7. Joysticks actually use two
level numbers. The first is for the X-axis and the second is for the Y-axis. You
only need to specify the first level. Record the channel code settings if you
want to create duplicate buttons and their functions on another page.
BUTTON TYPE
select the button type. After you select a button type, the Properties page re-
sets with specific options according to that button type. For example, if you
2, 1
2, 255
1,255
Opens the keypad where you set the device number for
Opens the keypad where you set the variable text
Opens the keypad where you set the device number for the
Opens the keypad where you set the number codes for the
Opens the BUTTON TYPE menus (Figure 145) where you
Touch Panel Program Reference
Channel code
number
Slider
Level channel
Level device
number
93
