Blank Bezel

To remove the blank bezel from the front bezel:
1. Perform the service preparations described on page 3-2.
2. Remove the following components:
workstation cover
front bezel
3. With the inside of the front bezel facing you, push the tab on the blank bezel to the
right .
4. Push the blank bezel out through the inside of the front bezel .
Figure 3-7. Removing the blank bezel
To replace the blank bezel and reassemble the workstation, reverse the above steps.
