Compaq AP400 Maintenance And Service Manual page 87

2. When you see the words "F10=Setup" in the bottom-right corner of the screen, press
F10. You have approximately two seconds to press F10 or you must restart the
workstation.
3. Select the desired language when prompted. Then press Enter to bypass the title and
welcome screens. The Compaq Utilities menu appears.
Computer Setup
The Computer Setup utility is preinstalled on the system partition. This utility is also available
on diskettes through SoftPaq, or by creating diskettes from the system partition. Computer Setup
provides a snapshot of the workstation hardware configuration, aids in troubleshooting, and
allows you to customize workstation features. Computer Setup recognizes a newly installed
internal or external device and automatically updates the Computer Setup screen.
The following parameters are checked:
Installed devices
Memory status
Password status
Interface configurations
Graphics configuration
Computer serial number
Controller status
Power Management
To run Computer Setup, follow these steps:
1. Access the Compaq Utilities menu by restarting your workstation and pressing F10 when
you see the words "F10=Setup" in the bottom-right corner of the screen. Select the
desired language when prompted. Then press Enter to bypass the title and welcome
screens.
2. Select Computer Setup from the Compaq Utilities menu, then press Enter.
3. Select the desired configuration settings, then save and exit.
Computer Checkup (TEST)
Computer Checkup (TEST), the primary diagnostics utility, confirms whether the various
workstation devices are recognized by the system and are functioning properly. Use the TEST
utility to help set up tests, to test the workstation, and to install the operating system. The TEST
menu offers the following:
Quick Check Diagnostics runs a quick, general test on each device with a minimal
number of prompts. If errors occur, they are displayed when the test is complete.
Automatic Diagnostics runs unattended and provides maximum testing of each device
with minimal prompts. You can choose how many times to run the tests, to stop on errors,
or to print or file an error log.
Compaq Professional Workstation AP400 Maintenance and Service Guide
4-15
